Zephyr ZSIE36ASES 36" Siena Wall Energy Star
The Siena Es, Certified Energy Star® Hood Is Packed With Power. With A 400-Cfm Blower And Act™ Te... Read more...
SKU:ZSIE36ASES
UPC:646328003608
The Siena Es, Certified Energy Star® Hood Is Packed With Power. With A 400-Cfm Blower And Act™ Technology This Hood Has A Versatile Range Of Features Perfect For Any Kitchen. With Energy-Efficient, Warm White Fluorescent Lights, An Extension Duct Cover Option And Zephyr'S New Icon Touch® Controls, Clearing The Air Is As Simple As The Touch Of A Button.
- 290, 400 CFM
- Not Recirculating
- Hybrid Baffle Filter
- Stainless Steel
- Vertical Ducting
- Max Sones 6
- Airflow Control Technology(TM) (ACT(TM))
- ENERGY STAR(R) Certified
- Fluorescent Lighting
- Hybrid Baffle Filters
- ICON Touch(R) Controls
- Optional Duct Cover Extension Kit
| UPC | 646328003608 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 400 |
| BLOWER CFM w/ACT | 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| CONTROLS TYPE | ICON Touch® |
| BLOWER SPEEDS | 3 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | no |
| LIGHTS TYPE (INCLUDED) | fluorescent |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 13 |
| LIGHTS LEVELS | 1 |
| FILTER TYPE | hybrid baffle |
| DUCT DISCHARGE | vertical |
| DUCT SIZE, VERTICAL, INCHES | 8 |
| DUCT SIZE, HORIZONTAL, INCHES | NA |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 34 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 1.2 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 35.875 |
| DEPTH, INCHES | 21.9375 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 27.5 - 42 |
| WEIGHT, LBS | 41.8 |
| SHIPPING HEIGHT, INCHES | 29.13 |
| SHIPPING WIDTH, INCHES | 41.65 |
| SHIPPING LENGTH, INCHES | 18.5 |
| SHIPPING WEIGHT, LBS | 55 |
Description
The Siena Es, Certified Energy Star® Hood Is Packed With Power. With A 400-Cfm Blower And Act™ Technology This Hood Has A Versatile Range Of Features Perfect For Any Kitchen. With Energy-Efficient, Warm White Fluorescent Lights, An Extension Duct Cover Option And Zephyr'S New Icon Touch® Controls, Clearing The Air Is As Simple As The Touch Of A Button.
Features
- 290, 400 CFM
- Not Recirculating
- Hybrid Baffle Filter
- Stainless Steel
- Vertical Ducting
- Max Sones 6
- Airflow Control Technology(TM) (ACT(TM))
- ENERGY STAR(R) Certified
- Fluorescent Lighting
- Hybrid Baffle Filters
- ICON Touch(R) Controls
- Optional Duct Cover Extension Kit
Specifications
| UPC | 646328003608 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 400 |
| BLOWER CFM w/ACT | 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| CONTROLS TYPE | ICON Touch® |
| BLOWER SPEEDS | 3 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | no |
| LIGHTS TYPE (INCLUDED) | fluorescent |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 13 |
| LIGHTS LEVELS | 1 |
| FILTER TYPE | hybrid baffle |
| DUCT DISCHARGE | vertical |
| DUCT SIZE, VERTICAL, INCHES | 8 |
| DUCT SIZE, HORIZONTAL, INCHES | NA |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 34 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 1.2 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 35.875 |
| DEPTH, INCHES | 21.9375 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 27.5 - 42 |
| WEIGHT, LBS | 41.8 |
| SHIPPING HEIGHT, INCHES | 29.13 |
| SHIPPING WIDTH, INCHES | 41.65 |
| SHIPPING LENGTH, INCHES | 18.5 |
| SHIPPING WEIGHT, LBS | 55 |
