Zephyr ZNAM90CS 36" Napoli Island

Zephyr ZNAM90CS 36" Napoli Island

Strong And Sophisticated With Upwardly-Angled Walls, Napoli Makes An Impression In Any Kitchen. U... Read more...

When Will I Get My Order?

x

Shipping calculated at checkout.
View full details

When Will I Get My Order?

x

Zephyr ZNAM90CS 36
Zephyr ZNAM90CS 36" Napoli Island
Strong And Sophisticated With Upwardly-Angled Walls, Napoli Makes An Impression In Any Kitchen. Upgraded With Zephyr'S Dcbl Suppression System® And Bloom™ Hd Led Light Bulbs, Napoli Is A Technological Achievement And A Cut Above The Rest. Now Including An Enhanced Quick-Lock Installation System With Magnetic Duct Covers, Napoli Is As Easy To Install As It Is To Enjoy. Now Available With An Optional Wireless Remote Control.
  • 290, 390, 590, 715 CFM
  • Recirculating
  • Baffle Filter
  • Stainless Steel
  • Vertical Ducting
  • Max Sones 5.8
  • Dual-Level Lighting
  • Bloom(TM) HD LED Light Bulbs
  • Airflow Control Technology(TM) (ACT(TM))
  • Baffle Filters
  • CleanAir Function
  • DCBL Suppression System(R)
  • Electronic LCD Controls
  • Optional Recirculating Kit
  • Optional Duct Cover Extension Kit
  • Optional Make-Up Air Kit
  • Optional Wireless Remote Control
  • Quick-Lock Installation System
  • Ultra-Quiet Performance
UPC 646328004087
BLOWER INCLUDED YES/NO yes
INTERNAL BLOWER 1 CFM 715
BLOWER CFM w/ACT 590, 390, 290
INTERNAL BLOWER 1 SONES 5.8
CONTROLS TYPE Electronic LCD
BLOWER SPEEDS 6
AUTOMATIC DELAY-OFF yes
CLEANAIR FUNCTION yes
LIGHTS TYPE (INCLUDED) Bloom™ HD LED
LIGHTS QUANTITY 4
WATTS PER BULB 3
LIGHTS LEVELS 2
FILTER TYPE baffle
DUCT DISCHARGE vertical
DUCT SIZE, VERTICAL, INCHES 8
DUCT SIZE, HORIZONTAL, INCHES NA
MOUNTING HEIGHT ABOVE COOKTOP, INCHES 26 - 34
INPUT VOLTAGE 120
MAXIMUM AMPERAGE 4
NOMINAL WIDTH, INCHES 36
NET WIDTH, INCHES 35.4375
DEPTH, INCHES 25.5625
HEIGHT, INCHES (for chimney hoods, heights include duct covers) 32 - 50
WEIGHT, LBS 62.7
SHIPPING HEIGHT, INCHES 32.05
SHIPPING WIDTH, INCHES 39.96
SHIPPING LENGTH, INCHES 23.23
SHIPPING WEIGHT, LBS 83.2
