Zephyr AK9234AS 36" Monsoon I One-Piece Liner With 600 Cfm Blower, 6 Speed Levels, Act
Zephyr'S Essentials Power Series Ak9234As Monsoon I One-Piece Liner Has Taken The One-Piece Liner... Read more...
SKU:AK9234AS
UPC:646328002618
Zephyr'S Essentials Power Series Ak9234As Monsoon I One-Piece Liner Has Taken The One-Piece Liner To The Next Level. Including Dual-Level Halogen Lights And An Ada-Compliant Rf Remote Control, You Can Easily Control The Monsoon I Without Ever Reaching Over A Hot, Dangerous Cooking Surface.
- Essential Power series Monsoon I one-piece liner
- ACT Airflow Control Technology (allows you to limit max. CFM to meet local code requirements)
- 34-3/8" width is perfect for 36 in. cooktops
- Mounting height: 26" - 36"
- Six powerful speed levels
- 200-600 CFM internal blower
- Internal blower sones: 1.2-6
- Stainless steel pro-baffle
- Electronic touch integrated controls
- Dual-level lighting
- Removable grease tray
- Two 35W halogen bulbs
- Includes wireless RF remote control
- Internal blower - vertical: 8" round
- Internal blower - horizontal: 8" round or 3-1/4" x 10"
| UPC | 646328002618 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 600 |
| BLOWER CFM w/ACT | 390, 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| CONTROLS TYPE | Electronic |
| BLOWER SPEEDS | 6 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | yes |
| LIGHTS TYPE (INCLUDED) | halogen |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 35 |
| LIGHTS LEVELS | 2 |
| FILTER TYPE | pro baffle |
| DUCT DISCHARGE | vertical or horizontal |
| DUCT SIZE, VERTICAL, INCHES | 8 |
| DUCT SIZE, HORIZONTAL, INCHES | 8, 3.25 x 10 |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 36 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 5 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 34.375 |
| DEPTH, INCHES | 19.25 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 12 |
| WEIGHT, LBS | 42.2 |
| SHIPPING HEIGHT, INCHES | 25.87 |
| SHIPPING WIDTH, INCHES | 37.99 |
| SHIPPING LENGTH, INCHES | 17.32 |
| SHIPPING WEIGHT, LBS | 53 |
Monsoon I, One-Piece Liner 34-3/8", SS, 600 CFM, ACT
Description
Zephyr'S Essentials Power Series Ak9234As Monsoon I One-Piece Liner Has Taken The One-Piece Liner To The Next Level. Including Dual-Level Halogen Lights And An Ada-Compliant Rf Remote Control, You Can Easily Control The Monsoon I Without Ever Reaching Over A Hot, Dangerous Cooking Surface.
Features
- Essential Power series Monsoon I one-piece liner
- ACT Airflow Control Technology (allows you to limit max. CFM to meet local code requirements)
- 34-3/8" width is perfect for 36 in. cooktops
- Mounting height: 26" - 36"
- Six powerful speed levels
- 200-600 CFM internal blower
- Internal blower sones: 1.2-6
- Stainless steel pro-baffle
- Electronic touch integrated controls
- Dual-level lighting
- Removable grease tray
- Two 35W halogen bulbs
- Includes wireless RF remote control
- Internal blower - vertical: 8" round
- Internal blower - horizontal: 8" round or 3-1/4" x 10"
Specifications
| UPC | 646328002618 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 600 |
| BLOWER CFM w/ACT | 390, 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| CONTROLS TYPE | Electronic |
| BLOWER SPEEDS | 6 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | yes |
| LIGHTS TYPE (INCLUDED) | halogen |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 35 |
| LIGHTS LEVELS | 2 |
| FILTER TYPE | pro baffle |
| DUCT DISCHARGE | vertical or horizontal |
| DUCT SIZE, VERTICAL, INCHES | 8 |
| DUCT SIZE, HORIZONTAL, INCHES | 8, 3.25 x 10 |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 36 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 5 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 34.375 |
| DEPTH, INCHES | 19.25 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 12 |
| WEIGHT, LBS | 42.2 |
| SHIPPING HEIGHT, INCHES | 25.87 |
| SHIPPING WIDTH, INCHES | 37.99 |
| SHIPPING LENGTH, INCHES | 17.32 |
| SHIPPING WEIGHT, LBS | 53 |
Videos
Monsoon I, One-Piece Liner 34-3/8", SS, 600 CFM, ACT
