Zephyr AK7036BS 36" Tempest I Wall Hood With 650 Cfm Blower, 6 Speed Levels, Act
The Zephyr Ak7036Bs 36-In. Essential Series Tempest I Under-Cabinet Pro-Style Range Hood Is A Str... Read more...
SKU:AK7036BS
UPC:646328003097
The Zephyr Ak7036Bs 36-In. Essential Series Tempest I Under-Cabinet Pro-Style Range Hood Is A Streamlined Under-Cabinet Pro-Style Range Hood. The Tempest I Combines Power, Efficiency And Flexibility. The 650-Cfm Blower And High Airflow Baffle Filters (That Are Also Dishwasher-Safe) Ensure A Lifetime Of Exceptional Performance.
- 36-In. Essential Series Tempest I under-cabinet pro-style range hood
- ACT Airflow Control Technology (built into Tempest I hoods with single internal blowers to limit maximum blower CFM to meet local code requirements)
- Six powerful speed levels
- 200-650 CFM single internal blower
- Internal blower sones: 1-6
- 36-In. wide design
- Three SS Pro-Baffle filters
- Electronic touch integrated controls
- Dual-level lighting
- Two 35W halogen bulbs
- Internal blower - vertical: 8" round
- Internal blower - horizontal: 8" round or 3-1/4" x 10"
- Optional wireless remote control (not included)
- Color: Stainless Steel
- Recirculating option
- Mounting height: 26" - 36"
| UPC | 646328003097 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 650 |
| INTERNAL BLOWER 2 CFM | 1200 |
| BLOWER CFM w/ACT | 390, 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| INTERNAL BLOWER 2 SONES | 9 |
| CONTROLS TYPE | Electronic |
| BLOWER SPEEDS | 6 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | yes |
| LIGHTS TYPE (INCLUDED) | halogen |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 35 |
| LIGHTS LEVELS | 2 |
| FILTER TYPE | pro baffle |
| DUCT DISCHARGE | vertical or horizontal |
| DUCT SIZE, VERTICAL, INCHES | 8, 10 |
| DUCT SIZE, HORIZONTAL, INCHES | 8, 3.25 x 10 |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 36 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 5 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 35.875 |
| DEPTH, INCHES | 22.5 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 11 |
| WEIGHT, LBS | 50.6 |
| SHIPPING HEIGHT, INCHES | 30 |
| SHIPPING WIDTH, INCHES | 40.94 |
| SHIPPING LENGTH, INCHES | 16.54 |
| SHIPPING WEIGHT, LBS | 62 |
Tempest I, 11in Pro, 36", SS, 650 CFM, ACT
Description
The Zephyr Ak7036Bs 36-In. Essential Series Tempest I Under-Cabinet Pro-Style Range Hood Is A Streamlined Under-Cabinet Pro-Style Range Hood. The Tempest I Combines Power, Efficiency And Flexibility. The 650-Cfm Blower And High Airflow Baffle Filters (That Are Also Dishwasher-Safe) Ensure A Lifetime Of Exceptional Performance.
Features
- 36-In. Essential Series Tempest I under-cabinet pro-style range hood
- ACT Airflow Control Technology (built into Tempest I hoods with single internal blowers to limit maximum blower CFM to meet local code requirements)
- Six powerful speed levels
- 200-650 CFM single internal blower
- Internal blower sones: 1-6
- 36-In. wide design
- Three SS Pro-Baffle filters
- Electronic touch integrated controls
- Dual-level lighting
- Two 35W halogen bulbs
- Internal blower - vertical: 8" round
- Internal blower - horizontal: 8" round or 3-1/4" x 10"
- Optional wireless remote control (not included)
- Color: Stainless Steel
- Recirculating option
- Mounting height: 26" - 36"
Specifications
| UPC | 646328003097 |
| BLOWER INCLUDED YES/NO | yes |
| INTERNAL BLOWER 1 CFM | 650 |
| INTERNAL BLOWER 2 CFM | 1200 |
| BLOWER CFM w/ACT | 390, 290 |
| INTERNAL BLOWER 1 SONES | 6 |
| INTERNAL BLOWER 2 SONES | 9 |
| CONTROLS TYPE | Electronic |
| BLOWER SPEEDS | 6 |
| AUTOMATIC DELAY-OFF | yes |
| CLEANAIR FUNCTION | yes |
| LIGHTS TYPE (INCLUDED) | halogen |
| LIGHTS QUANTITY | 2 |
| WATTS PER BULB | 35 |
| LIGHTS LEVELS | 2 |
| FILTER TYPE | pro baffle |
| DUCT DISCHARGE | vertical or horizontal |
| DUCT SIZE, VERTICAL, INCHES | 8, 10 |
| DUCT SIZE, HORIZONTAL, INCHES | 8, 3.25 x 10 |
| MOUNTING HEIGHT ABOVE COOKTOP, INCHES | 26 - 36 |
| INPUT VOLTAGE | 120 |
| MAXIMUM AMPERAGE | 5 |
| NOMINAL WIDTH, INCHES | 36 |
| NET WIDTH, INCHES | 35.875 |
| DEPTH, INCHES | 22.5 |
| HEIGHT, INCHES (for chimney hoods, heights include duct covers) | 11 |
| WEIGHT, LBS | 50.6 |
| SHIPPING HEIGHT, INCHES | 30 |
| SHIPPING WIDTH, INCHES | 40.94 |
| SHIPPING LENGTH, INCHES | 16.54 |
| SHIPPING WEIGHT, LBS | 62 |
