Home > Zephyr ADLM90BSX 36" Duo Island
  • Zephyr ADLM90BSX 36
  • Zephyr ADLM90BSX 36
  • Zephyr ADLM90BSX 36
  • Zephyr ADLM90BSX 36
  • Zephyr ADLM90BSX 36" Duo Island

    An Ideal Duo Of Materials, Duo Can Be Paired With A Wood Overlay Using Our Template As The Guide.... Read more...

    Click to Call

    To order or learn more please call us at: 800-288-1647

    When Will I Get My Order?
    An Ideal Duo Of Materials, Duo Can Be Paired With A Wood Overlay Using Our Template As The Guide. Or, If You Prefer The Simplicity Of A Slim Profile Stainless Steel Canopy, Keep The Duo Island As-Is; For The Stylish, And Contemporary Kitchen. Now Available With Tri-Level Led Light Strips.
    • 290, 600, 1000 CFM
    • Recirculating
    • Mesh Filter
    • Stainless Steel
    • Vertical Ducting
    • Tri-level Lighting
    • Capacitive Touch Controls
    • CleanAir Function
    • Decorative Mesh Filters
    • Includes Wireless Remote Control
    • LED Light Strip
    • Low-Profile Body
    • Multiple Blower Options
    • Optional Recirculating Kit
    • Optional Duct Cover Extension Kit
    UPC 646328004209
    BLOWER INCLUDED YES/NO no
    INTERNAL BLOWER 1 CFM 290
    INTERNAL BLOWER 2 CFM 600
    IN-LINE BLOWER CFM 1000
    EXTERNAL BLOWER CFM 1000
    INTERNAL BLOWER 1 SONES 3
    INTERNAL BLOWER 2 SONES 6
    CONTROLS TYPE Capacitive touch
    BLOWER SPEEDS 3
    AUTOMATIC DELAY-OFF yes
    CLEANAIR FUNCTION yes
    LIGHTS TYPE (INCLUDED) LED strip
    LIGHTS QUANTITY 2
    WATTS PER BULB 8.5
    LIGHTS LEVELS 3
    FILTER TYPE decorative mesh
    DUCT DISCHARGE vertical
    DUCT SIZE, VERTICAL, INCHES 6, 8
    DUCT SIZE, HORIZONTAL, INCHES NA
    MOUNTING HEIGHT ABOVE COOKTOP, INCHES 24 - 36
    INPUT VOLTAGE 120
    MAXIMUM AMPERAGE depends on blower
    NOMINAL WIDTH, INCHES 36
    NET WIDTH, INCHES 35.375
    DEPTH, INCHES 23.625
    HEIGHT, INCHES (for chimney hoods, heights include duct covers) 29.5 - 49
    WEIGHT, LBS 101
    SHIPPING HEIGHT, INCHES 31.5
    SHIPPING WIDTH, INCHES 40.55
    SHIPPING LENGTH, INCHES 20.87
    SHIPPING WEIGHT, LBS 110.2

    Description

    An Ideal Duo Of Materials, Duo Can Be Paired With A Wood Overlay Using Our Template As The Guide. Or, If You Prefer The Simplicity Of A Slim Profile Stainless Steel Canopy, Keep The Duo Island As-Is; For The Stylish, And Contemporary Kitchen. Now Available With Tri-Level Led Light Strips.

    Features

    • 290, 600, 1000 CFM
    • Recirculating
    • Mesh Filter
    • Stainless Steel
    • Vertical Ducting
    • Tri-level Lighting
    • Capacitive Touch Controls
    • CleanAir Function
    • Decorative Mesh Filters
    • Includes Wireless Remote Control
    • LED Light Strip
    • Low-Profile Body
    • Multiple Blower Options
    • Optional Recirculating Kit
    • Optional Duct Cover Extension Kit

    Specifications

    UPC 646328004209
    BLOWER INCLUDED YES/NO no
    INTERNAL BLOWER 1 CFM 290
    INTERNAL BLOWER 2 CFM 600
    IN-LINE BLOWER CFM 1000
    EXTERNAL BLOWER CFM 1000
    INTERNAL BLOWER 1 SONES 3
    INTERNAL BLOWER 2 SONES 6
    CONTROLS TYPE Capacitive touch
    BLOWER SPEEDS 3
    AUTOMATIC DELAY-OFF yes
    CLEANAIR FUNCTION yes
    LIGHTS TYPE (INCLUDED) LED strip
    LIGHTS QUANTITY 2
    WATTS PER BULB 8.5
    LIGHTS LEVELS 3
    FILTER TYPE decorative mesh
    DUCT DISCHARGE vertical
    DUCT SIZE, VERTICAL, INCHES 6, 8
    DUCT SIZE, HORIZONTAL, INCHES NA
    MOUNTING HEIGHT ABOVE COOKTOP, INCHES 24 - 36
    INPUT VOLTAGE 120
    MAXIMUM AMPERAGE depends on blower
    NOMINAL WIDTH, INCHES 36
    NET WIDTH, INCHES 35.375
    DEPTH, INCHES 23.625
    HEIGHT, INCHES (for chimney hoods, heights include duct covers) 29.5 - 49
    WEIGHT, LBS 101
    SHIPPING HEIGHT, INCHES 31.5
    SHIPPING WIDTH, INCHES 40.55
    SHIPPING LENGTH, INCHES 20.87
    SHIPPING WEIGHT, LBS 110.2
