Summit CT66LWBISSHV 24" Wide Built-In Refrigerator-Freezer
Stainless Steel Door Complete With Sleek Handle Adds Modern Elegance To Any Setting Factory Installed Lock Provides Security You Can Count On Flexible Design Allows Built-In Or Freestanding Use In 24" Spaces Improved Temperature Performance With Our Unique Dual Evaporator Cooling Includes Door Storage And Adjustable Shelves Over 5 Cu.Ft. Of Storage Capacity In A Perfectly Sized 24" Footprint Made In Europe Accucold By Summit Appliance Offers A Wide Range Of Undercounter Refrigeration For General Purpose Storage. The Ct66Jbi Series Includes Built-In Undercounter Refrigerator-Freezers Equipped With Dual Evaporator Cooling For Optimum Storage Conditions. Sized With A 24" Footprint, The Ct66Lwbisshv Can Be Used Built-In Under Counters Or Freestanding. The Interior Offers Over 5 Cu.Ft. Of Storage Capacity. This Model Has A White Cabinet And Reversible Stainless Steel Wrapped Door With A Factory Installed Front Lock. A Thin Handle With A 14Mm Diameter Completes The Sleek, Modern Look. Inside, Our Unique Dual Evaporator System Separately Cools The Refrigerator And Freezer Section To Ensure Proper Storage Temperature. Cycle Defrost Operation Reduces User Maintenance In The Automatic Defrost Fresh Food Section, With Static Manual Defrost Operation In The Freezer Compartment. Door Storage Provides Easy Access For Tall Bottles And Small Condiments. Additional Features Include Adjustable Shelves, A Clear Crisper, And Automatic Interior Lighting. The Ct66Lwbisshv Has Long Proven Itself To Have One Of The Best Temperature Performance Records In The Industry. To See Additional Finish Options On This Unit, Browse The Full Ct66Jbi Series. Note: This Unit Is Designed For General Purpose Applications And Does Not Meet Doe Energy Standards For Residential Use.
- Slim undercounter dimensions : Less than 24 inches wide to fit tight spaces
- Factory installed lock : Keyed lock offers added security
- Built-in capable : Make the best use of space by installing your appliance under the counter and flush with other cabinetry
- Fully finished white cabinet : Allows the unit to be used freestanding
- Height Adjustable : Adjustable legs allow the unit to be sized from 33 1/2" to 34 3/4" high
- Stainless steel door : Durable design with lasting elegance
- Professional stainless steel handle : Thin 14mm diameter on stainless steel handle, mounted vertically for a sleek look
- Cycle defrost : This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
- Dual evaporator cooling : Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
- Adjustable shelves : Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
- Crisper drawer : Get the longest life and best taste out of produce by storing greens in lower slide drawer
- Door shelves : Store tall bottles and condiments right on the door for convenient access
- Interior light : Automatically illuminates when the door is opened
- Adjustable thermostat : Dial thermostat located inside for easy temperature management
- 100% CFC free : Environmentally friendly design does not contain ozone-damaging chemicals
Overview | |
Height of Cabinet | 33.5' (85 cm) |
Width | 23.63' (60 cm) |
Depth | 23.5' (60 cm) |
Depth with Handle | 25.63' (65 cm) |
Depth with door at 90° | 45.63' (116 cm) |
Capacity | 5.1 cu.ft. (144 L) |
Defrost Type | Cycle |
Door | Stainless Steel |
Cabinet | White |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Amps | 1.4 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 100.0 lbs. (45 kg) |
Shipping Weight | 105.0 lbs. (48 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101068886 |
Refrigerator-Freezer | |
Door Swing | RHD |
Reversible | Factory Reversible |
Crisper Qty | 1 |
Crisper Finish | Transparent |
Crisper Cover | Wire |
Interior Light | Yes |
Refrigerator - Interior Height | 19.5' (50 cm) |
Refrigerator - Interior Width | 20.5' (52 cm) |
Refrigerator - Interior Depth | 17.0' (43 cm) |
Refrigerator - Shelf Type | Wire |
Refrigerator - Shelf Qty | 2 |
Refrigerator - Full Door Shelves | 3 |
Freezer - Interior Height | 5.0' (13 cm) |
Freezer - Interior Width | 19.0' (48 cm) |
Freezer - Interior Depth | 11.5' (29 cm) |
Thermostat Type | Dial |
Fan Type | Exterior |
Refrigerant Type | R600a |
Refrigerant Amount | 0.92 oz. |
High Side PSI | 180.0 |
Low Side PSI | 80.0 |
Level Legs | 4 |
Compressor Step Height | 7.0' (18 cm) |
Compressor Step Width | 20.5' (52 cm) |
Compressor Step Depth | 5.0' (13 cm) |
Exterior | |
DL2B - Factory installed NIST calibrated digital data logger (DDL) | TT - Installed thermometer |
PH - Probe Hole | Legs to raise unit height |
CAS6 6' casters | CAS3 3' casters |
Alarm | Extra key |
SS Hinges | SCD - Self-closing door |
ODA - Open door alarm | LHD - Left hand door swing |
Latch for door | SSK |
HG - Hospital grade cord | DL1 - Factory installed data logger |
Agion Door | - |
Interior | |
FCGP internal fan with gel packs | FC - Internal Fan |
Handle | |
TBC Copper Towel Bar Handle Upgrade | - |
Door | |
STO-Step-To-Open Door Pedal | - |
