Stainless steel design

graceful curves and lines creates a distinct appearance that enhances any kitchen
350 CFM, four-speed fan

Provides the power necessary to capture smoke and fumes produced by high-performance cooking equipment
Four halogen lights

Offer six levels of intensity, from ambient to low/night illumination, to meet different needs
Three removable filters

Trap airborne grease particles and are dishwasher-safe. An indicator light signals when the filters need cleaning.
- Stainless steel design
- graceful curves and lines creates a distinct appearance that enhances any kitchen
- 350 CFM, four-speed fan
- Provides the power necessary to capture smoke and fumes produced by high-performance cooking equipment
- Four halogen lights
- Offer six levels of intensity, from ambient to low/night illumination, to meet different needs
- Three removable filters
- Trap airborne grease particles and are dishwasher-safe. An indicator light signals when the filters need cleaning.
- Timer
- Can be set for the fan to automatically shut-off after 5, 10 or 20 minutes of operation
- Optional recirculating kit (included)
- Can be installed for internal ventilation
APPEARANCE | |
Exterior Design | Chimney - Island |
Design Style | Chimney |
Color Appearance | Stainless Steel |
WARRANTY | |
Warranty Notes | See written warranty for full details |
Parts Warranty | Limited 2-year entire appliance |
Labor Warranty | Limited 2-year entire appliance |
POWER / RATINGS | |
Amp Rating at 120V | 3.74 |
ACCESSORIES | |
Optional 10' Ceiling Extension | ZX8510SPSS for 9.5' to 10' ceilings |
WEIGHTS & DIMENSIONS | |
Net Weight | 76.0 |
Overall Depth | 27.5 |
Overall Width | 36.5 |
Overall Height | 41.5 |
Approximate Shipping Weight | 106.0 |
Cabinet Width | 36.0 |
FEATURES | |
Filter Cleaning Reminders | Yes |
Vertical Exhaust Blower Rating (CFM) | 350 |
Recirculating Capable | Yes, Included |
Lighting Levels | 6 |
Blower Levels | 4 Including Boost |
Variable Speed Fan | Yes |
Exhaust Options | 6' Round Duct (Extends to 8' Ceiling) |
Cooktop Lighting | 4 Halogen |
Control Type | 8 Pushbuttons Electronic |
Removable Stainless Steel Filters | 3 |
Damper in Transition | Yes |
Time Delay Shut-Off | Yes |
Overview
Stainless steel design

graceful curves and lines creates a distinct appearance that enhances any kitchen
350 CFM, four-speed fan

Provides the power necessary to capture smoke and fumes produced by high-performance cooking equipment
Four halogen lights

Offer six levels of intensity, from ambient to low/night illumination, to meet different needs
Three removable filters

Trap airborne grease particles and are dishwasher-safe. An indicator light signals when the filters need cleaning.
Description
Features
- Stainless steel design
- 350 CFM, four-speed fan
- Four halogen lights
- Three removable filters
- Timer
- Optional recirculating kit (included)
Specifications
APPEARANCE | |
Exterior Design | Chimney - Island |
Design Style | Chimney |
Color Appearance | Stainless Steel |
WARRANTY | |
Warranty Notes | See written warranty for full details |
Parts Warranty | Limited 2-year entire appliance |
Labor Warranty | Limited 2-year entire appliance |
POWER / RATINGS | |
Amp Rating at 120V | 3.74 |
ACCESSORIES | |
Optional 10' Ceiling Extension | ZX8510SPSS for 9.5' to 10' ceilings |
WEIGHTS & DIMENSIONS | |
Net Weight | 76.0 |
Overall Depth | 27.5 |
Overall Width | 36.5 |
Overall Height | 41.5 |
Approximate Shipping Weight | 106.0 |
Cabinet Width | 36.0 |
FEATURES | |
Filter Cleaning Reminders | Yes |
Vertical Exhaust Blower Rating (CFM) | 350 |
Recirculating Capable | Yes, Included |
Lighting Levels | 6 |
Blower Levels | 4 Including Boost |
Variable Speed Fan | Yes |
Exhaust Options | 6' Round Duct (Extends to 8' Ceiling) |
Cooktop Lighting | 4 Halogen |
Control Type | 8 Pushbuttons Electronic |
Removable Stainless Steel Filters | 3 |
Damper in Transition | Yes |
Time Delay Shut-Off | Yes |
