Lg LW1223HRSM 12,200 Btu Smart Wi-Fi Enabled Window Air Conditioner, Cooling & Heating

Maximum Usability
Operate with LED display and simple selection control panel, up/down temperature adjustments, and fan speed selection, using the full-featured remote without leaving your bed, workspace, or couch.

Quiet Operation
LG window air conditioners operate at sound levels as low as 50dB (when in low mode) eliminating unnecessary noise for smooth operation that you'll barely notice.

Cooling & Heating
LG window air conditioners provide powerful cooling and heating. Stay comfortable all year long, even in extreme climate, with our advanced technology.

Made to Perfection
LG window air conditioners add powerful performance and stable durability to perfectly match your window frame.
Stay cool as the summer heats up with this LG Smart Wi-Fi Window Air Conditioner. Designed to fit perfectly inside your window frame, you can cool your space without disrupting your design. This air conditioner has 12,200 BTUs and can cool spaces up to 550 square feet. The 11,200 Heating BTU provides supplemental heating to warm the room on those unexpectedly chilly nights without heating the entire house. Two fan speeds, a 24-hour on/off timer, and four operation modes make it easy to find and set your preferred temperature. This Smart Window Air Conditioner includes a remote control, so you can easily adjust settings from across the room or on the couch.
Dimensions & Capacity
Width: 23.62"
Height: 15"
Depth: 22.33"
Cooling Power: 12200 btu
Heating Power: 11200 btu
- Cooling: 12,200 BTU / Heating: 11,200 BTU
- Estimated Cooling Area 570 Sq. Ft
- LG ThinQ® Technology
- Multiple Cooling / Heating Speeds
- Easy To Use Electronic Controls
- Window Installation Kit Included
COMPONENTS | |
Cord Length | 52' |
COMPRESSOR | |
Compressor | Rotary |
DIMENSIONS/WEIGHT | |
Net Weight (lbs.) | 86 lbs |
Product Dimension (WxHxD) | 23 5/8' x 15' x 22' |
Shipping Dimension (WxHxD) | 27 1/6' x 18 2/3' x 23 5/8' |
Shipping Weight (lbs.) | 93 lbs |
ELECTRICAL RATINGS | |
Plug Type | 208/230/20 Amp |
Rated Amps (Cooling) | 5.1/4.8 |
Rated Amps (Heating) | 14.0/15.3 |
Voltage / 60 Hz | 208/230V |
Watts (Cooling) | 1,030/1,060 |
Watts (Heating) | 2,900/3,500 |
FEATURES | |
Air Deflection | 4-Way |
Air Discharge Type | Side Discharge |
Air Filter | Yes |
Auto Restart | Yes |
Chassis Type | Slide In-Out |
Energy Saver Function | Yes |
Fan Speed Cooling | 2 |
Fan Speed Heating | 2 |
Fan Speed Only | 2 |
Filter Alarm Function | Yes |
Indoor Fan Type | Blower |
Remote Control | Yes |
Thermostat Control | Thermistor |
Timer | 24 Hr, On/Off |
Wi-Fi Connection | Yes |
Window Installation Kit | Yes |
PERFORMANCE | |
BTU Performance | 12,200 |
BTU performance (Cooling) | 11,700/12,200 |
BTU Performance (Heating) | 9,200/11,200 |
CEER | 11.6 |
dBA Level (High/Mid/Low/Sleep) | 58/-/54/- |
Dehumid. (Pts/Hr) | 3.5 |
Dry Air Flow (CFM) | 320 |
Est. Cooling Area (Sq. Ft.) | 570 |
SUMMARY | |
Air Type | Cooling & Heating |
Type | Window Air Conditioner |
UPC CODES | |
UPC | 048231606455 |
WARRANTY | |
Parts & Labor | 1 Year |
Energy Guide
Owner's Manual English 4,737K 10/12/2023
Owner's Manual Spanish 4,750K 10/12/2023
