Lg LW1223HRSM 12,200 Btu Smart Wi-Fi Enabled Window Air Conditioner, Cooling & Heating
SKU:LW1223HRSM
Installation and Removal
Where will services be needed?
When Will I Get My Order?
- Cooling: 12,200 BTU / Heating: 11,200 BTU
- Estimated Cooling Area 570 Sq. Ft
- LG ThinQ® Technology
- Multiple Cooling / Heating Speeds
- Easy To Use Electronic Controls
- Window Installation Kit Included
| COMPONENTS | |
| Cord Length | 52' |
| COMPRESSOR | |
| Compressor | Rotary |
| DIMENSIONS/WEIGHT | |
| Net Weight (lbs.) | 86 lbs |
| Product Dimension (WxHxD) | 23 5/8' x 15' x 22' |
| Shipping Dimension (WxHxD) | 27 1/6' x 18 2/3' x 23 5/8' |
| Shipping Weight (lbs.) | 93 lbs |
| ELECTRICAL RATINGS | |
| Plug Type | 208/230/20 Amp |
| Rated Amps (Cooling) | 5.1/4.8 |
| Rated Amps (Heating) | 14.0/15.3 |
| Voltage / 60 Hz | 208/230V |
| Watts (Cooling) | 1,030/1,060 |
| Watts (Heating) | 2,900/3,500 |
| FEATURES | |
| Air Deflection | 4-Way |
| Air Discharge Type | Side Discharge |
| Air Filter | Yes |
| Auto Restart | Yes |
| Chassis Type | Slide In-Out |
| Energy Saver Function | Yes |
| Fan Speed Cooling | 2 |
| Fan Speed Heating | 2 |
| Fan Speed Only | 2 |
| Filter Alarm Function | Yes |
| Indoor Fan Type | Blower |
| Remote Control | Yes |
| Thermostat Control | Thermistor |
| Timer | 24 Hr, On/Off |
| Wi-Fi Connection | Yes |
| Window Installation Kit | Yes |
| PERFORMANCE | |
| BTU Performance | 12,200 |
| BTU performance (Cooling) | 11,700/12,200 |
| BTU Performance (Heating) | 9,200/11,200 |
| CEER | 11.6 |
| dBA Level (High/Mid/Low/Sleep) | 58/-/54/- |
| Dehumid. (Pts/Hr) | 3.5 |
| Dry Air Flow (CFM) | 320 |
| Est. Cooling Area (Sq. Ft.) | 570 |
| SUMMARY | |
| Air Type | Cooling & Heating |
| Type | Window Air Conditioner |
| UPC CODES | |
| UPC | 048231606455 |
| WARRANTY | |
| Parts & Labor | 1 Year |
Features
- Cooling: 12,200 BTU / Heating: 11,200 BTU
- Estimated Cooling Area 570 Sq. Ft
- LG ThinQ® Technology
- Multiple Cooling / Heating Speeds
- Easy To Use Electronic Controls
- Window Installation Kit Included
Specifications
| COMPONENTS | |
| Cord Length | 52' |
| COMPRESSOR | |
| Compressor | Rotary |
| DIMENSIONS/WEIGHT | |
| Net Weight (lbs.) | 86 lbs |
| Product Dimension (WxHxD) | 23 5/8' x 15' x 22' |
| Shipping Dimension (WxHxD) | 27 1/6' x 18 2/3' x 23 5/8' |
| Shipping Weight (lbs.) | 93 lbs |
| ELECTRICAL RATINGS | |
| Plug Type | 208/230/20 Amp |
| Rated Amps (Cooling) | 5.1/4.8 |
| Rated Amps (Heating) | 14.0/15.3 |
| Voltage / 60 Hz | 208/230V |
| Watts (Cooling) | 1,030/1,060 |
| Watts (Heating) | 2,900/3,500 |
| FEATURES | |
| Air Deflection | 4-Way |
| Air Discharge Type | Side Discharge |
| Air Filter | Yes |
| Auto Restart | Yes |
| Chassis Type | Slide In-Out |
| Energy Saver Function | Yes |
| Fan Speed Cooling | 2 |
| Fan Speed Heating | 2 |
| Fan Speed Only | 2 |
| Filter Alarm Function | Yes |
| Indoor Fan Type | Blower |
| Remote Control | Yes |
| Thermostat Control | Thermistor |
| Timer | 24 Hr, On/Off |
| Wi-Fi Connection | Yes |
| Window Installation Kit | Yes |
| PERFORMANCE | |
| BTU Performance | 12,200 |
| BTU performance (Cooling) | 11,700/12,200 |
| BTU Performance (Heating) | 9,200/11,200 |
| CEER | 11.6 |
| dBA Level (High/Mid/Low/Sleep) | 58/-/54/- |
| Dehumid. (Pts/Hr) | 3.5 |
| Dry Air Flow (CFM) | 320 |
| Est. Cooling Area (Sq. Ft.) | 570 |
| SUMMARY | |
| Air Type | Cooling & Heating |
| Type | Window Air Conditioner |
| UPC CODES | |
| UPC | 048231606455 |
| WARRANTY | |
| Parts & Labor | 1 Year |
