Fully Flush Installation with Articulating Hinge

allows the ice maker's door to sit flush without protruding or leaving a gap between the ice maker and the adjoining cabinets. Articulating hinge design allows the door to open 90 degrees without swinging beyond its normal closed width, providing a built-in look that adds a touch of style to your kitchen or bar space.
Self-Cleaning Cycle

makes routine maintenance easy using a "clean cycle" and Affresh(R) ice maker cleaner.
PrintShield Finish

resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up.
Filter-Ready

provides a dedicated space where a filter can be inserted to help remove contaminants, improving taste and clarity. A filter is not required but can be purchased separately. Use filter #F2WC9I1 and change every six months for best results.
- Fully Flush Installation with Articulating Hinge
- allows the ice maker's door to sit flush without protruding or leaving a gap between the ice maker and the adjoining cabinets. Articulating hinge design allows the door to open 90 degrees without swinging beyond its normal closed width, providing a built-in look that adds a touch of style to your kitchen or bar space.
- Self-Cleaning Cycle
- makes routine maintenance easy using a "clean cycle" and Affresh(R) ice maker cleaner.
- PrintShield Finish
- resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up.
- Filter-Ready
- provides a dedicated space where a filter can be inserted to help remove contaminants, improving taste and clarity. A filter is not required but can be purchased separately. Use filter #F2WC9I1 and change every six months for best results.
Specifications | |
Dimensions | |
Cabinet Width | 14-7/8 in |
Cutout Depth | 25.0 in |
Cutout Height | 34-1/2 in |
Cutout Width | 15.0 in |
Depth Closed Excluding Handles | 24.0 in |
Depth Closed Including Handles | 25-3/8 in |
Depth Excluding Doors | 22-1/8 in |
Depth With Door Open 90 Degree | 39-1/2 in |
Height To Top Of Cabinet | 33-5/8 in |
Height To Top Of Door Hinge | 34-1/16 in |
Appearance | |
Cabinet Finish | Textured |
Handle Location | Horizontal |
Handle Material | Metal |
Reversible Door | Yes |
Controls | |
Defrost Type | Automatic Defrost |
Ice Maker On/Off | Yes |
Location of Controls | Interior Up Front |
Filter Details | |
Water Filter Indicator/Reset | Yes |
Water Filter Location | Interior |
Details | |
Ambient Temperature Range | 55F to 110F |
Drain Connection | Rear Access 5/8'' OD |
Drain Pump | Pump Included |
Ice Capacity Storage | 25 |
Interior Light | LED |
Certifications | |
Energy Star® Qualified | No |
Ice Maker Features | |
Selections | Ice Scoop, Max Ice, Articulating Hinge, Clear Ice Technology, True Flush Installable, Easy Access Filter Install |
Filters | |
Water Filter Part Number | F2WC9I1 |
Filter
Flush-install
Max ice
Printshield
Reversible-door
Overview
Fully Flush Installation with Articulating Hinge

allows the ice maker's door to sit flush without protruding or leaving a gap between the ice maker and the adjoining cabinets. Articulating hinge design allows the door to open 90 degrees without swinging beyond its normal closed width, providing a built-in look that adds a touch of style to your kitchen or bar space.
Self-Cleaning Cycle

makes routine maintenance easy using a "clean cycle" and Affresh(R) ice maker cleaner.
PrintShield Finish

resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up.
Filter-Ready

provides a dedicated space where a filter can be inserted to help remove contaminants, improving taste and clarity. A filter is not required but can be purchased separately. Use filter #F2WC9I1 and change every six months for best results.
Description
Features
- Clear Ice Technology - provides cubes of uniform 3/4" x 3/4" x 1/2" size and shape that are ideal for daily use or a variety of entertaining needs. Clear Ice Technology allows for attractive drink presentation and a slow melt rate so beverages won't water down quickly.
- Factory Installed Drain Pump
- Holds 25 Pounds of Ice - ensures a generous supply of fresh ice is conveniently at your fingertips.
- Max Ice
- Reversible Door - offers flexible installation options by allowing hinge installation on either side of the door.
Specifications
Specifications | |
Dimensions | |
Cabinet Width | 14-7/8 in |
Cutout Depth | 25.0 in |
Cutout Height | 34-1/2 in |
Cutout Width | 15.0 in |
Depth Closed Excluding Handles | 24.0 in |
Depth Closed Including Handles | 25-3/8 in |
Depth Excluding Doors | 22-1/8 in |
Depth With Door Open 90 Degree | 39-1/2 in |
Height To Top Of Cabinet | 33-5/8 in |
Height To Top Of Door Hinge | 34-1/16 in |
Appearance | |
Cabinet Finish | Textured |
Handle Location | Horizontal |
Handle Material | Metal |
Reversible Door | Yes |
Controls | |
Defrost Type | Automatic Defrost |
Ice Maker On/Off | Yes |
Location of Controls | Interior Up Front |
Filter Details | |
Water Filter Indicator/Reset | Yes |
Water Filter Location | Interior |
Details | |
Ambient Temperature Range | 55F to 110F |
Drain Connection | Rear Access 5/8'' OD |
Drain Pump | Pump Included |
Ice Capacity Storage | 25 |
Interior Light | LED |
Certifications | |
Energy Star® Qualified | No |
Ice Maker Features | |
Selections | Ice Scoop, Max Ice, Articulating Hinge, Clear Ice Technology, True Flush Installable, Easy Access Filter Install |
Filters | |
Water Filter Part Number | F2WC9I1 |
