Kitchenaid KOSC504ESS 24" Single Wall Oven With True Convection - Stainless Steel
Kitchenaid KOSC504ESS 24" Single Wall Oven With True Convection - Stainless Steel
Colors:
Stainless SteelTHIS ITEM QUALIFIES FOR FREE DELIVERY!
Call us at (800) 288-1647 for expert assistance in finding the perfect alternative.
Couldn't load pickup availability
When Will I Get My Order?
x
Kitchenaid KOSC504ESS 24" Single Wall Oven With True Convection - Stainless Steel
True Convection Oven
Features a heating element hidden behind a baffle that helps provide more even temperature management. The fan draws air in, past the heating element, and back into the oven.
Professionally-Inspired Design
Combines a bold blend of professionally-inspired styling with sleek touches for the home. This beautiful built-in wall oven features Satin Textured Handles and the KitchenAid(R) Badge, a symbol of uncompromised quality.
Even-Heat Preheat
Helps remove cold spots to help ensure even baking because the entire oven, including the walls and racks, are heated to the correct temperature.
- Broil Element - Combines the high power and even coverage needed to achieve results similar to outdoor grilling results.
- Baking Stone - offers a 13" square surface ideal for cooking pizza with a crispy pizzeria-style crust as well as breads, cookies, pastries and other baked goods. Heat is distributed evenly across its surface to maintain a consistent temperature and its flat surface releases food quickly and easily.
- Self Cleaning Cycle - Uses high temperature to power through soils in the oven cavity, requiring only a quick wipe down at the end of the cycle.
- Electronic Controls with Control Lock Function - Makes the oven easy to use. The intuitive left-to-right display makes it easy to control all oven functions and includes a control lock function that makes it easy to clean and prevents unwanted operation.
- 3.1 Cu. Ft. Capacity - The spacious capacity simultaneously accommodates multiple dishes.
| Specifications | |
| Dimensions | |
| Capacity | 3-1/10 |
| Cutout Depth | 23-1/4 in |
| Cutout Height | 27-3/4 in |
| Cutout Width | 22-5/8 in |
| Depth | 25-3/4 in |
| Height | 29.0 in |
| Oven Capacity | 3.1 cu. ft. |
| Width | 23-3/4 in |
| Configuration and Overview | |
| ADA Compliant | ADA Height and Side and Front Reach Compliant |
| CUL | Yes |
| Fuel Type | Electric |
| LP Convertible | No |
| Oven Type | Single |
| Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
| Size | 24 in |
| UL | UL |
| Oven Details | |
| Automatic Shut-Off | Yes |
| Bake Element Power | 2000W |
| Broiler Location | Top of Oven |
| Convection Element Type | True |
| Convection Functions | Bake, Broil, Roast |
| Door Broil Position | Closed |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Interior Coating | Porcelain |
| Interior Color | Grey |
| Language Conversion | English/French |
| Light Type | Halogen |
| Number of Oven Lights | 2 |
| Number of Oven Racks | 3 |
| Number of Rack Guides | 5 |
| Oven Cooking System | Convection |
| Oven Interior Depth | 17-5/8 in |
| Oven Interior Height | 16.0 in |
| Oven Interior Width | 19.0 in |
| Oven Rack 1 Type | Standard |
| Oven Rack 2 Type | Standard |
| Oven Rack 3 Type | Standard |
| Self-Cleaning Oven Racks | No |
| Temperature Conversion | Yes |
| Appearance | |
| Door Type | Metal & Glass |
| Flush Installation Approved | No |
| Handle Color | Stainless Steel |
| Handle Material | Metal |
| Details | |
| Bake Element Power | 2000W |
| Broiler Element Power | 3600W |
| Convection Element Type | True |
| Number of Rack Guides | 5 |
| Oven Cleaning Type | Self-Cleaning |
| Controls | |
| Electronic Display Type | White |
| Exterior | |
| Oven Window Size | Large |
