Kitchenaid KICU509XSS 30-Inch 4 Element Induction Cooktop, Architect® Series Ii - Stainless Steel
This 30-inch induction cooktop uses electromagnetic energy to generate instant heat directly to y... Read more...
SKU:KICU509XSS
UPC:883049231457
Colors:
Stainless Steel
BlackRebates
KitchenAid Buy More Save More Delivery and Installation Allowance - Enjoy exclusive rebate savings with purchase of qualifying KitchenAid appliances. Download Valid: 03/01/2023-04/30/2023
This 30-inch induction cooktop uses electromagnetic energy to generate instant heat directly to your cookware without spreading the heat across the entire cooking surface. A bridge function lets you combine the power of two elements into one large cooking zone for specialty cookware such as a griddle or oval pan.
4-Element Cooktop
Provides four independent cooking surface areas.
2 Elements with Bridge Function
Allows the flexibility to convert two cooking zones into one large cooking zone which provides additional space to accommodate specialty cookware.
12 Heat Level Settings
Provide various levels of heat to fine tune cooking techniques ranging from melting chocolate and simmering a sauce to searing meat or achieving a rapid boil.
- Performance Boost - Allows you to exceed the maximum heat-level setting for up to 10 minutes, perfect for rapid boiling
- Touch-Activated Controls - Integrate seamlessly into the surface and include a slider for heat-level selection
- Melt and Hold - Uses low power levels for melting delicate ingredients or keeping cooked food warm without scorching.
- Simmer Function - Automatically selects a low power level to help maintain a constant simmer without boiling over.
- Pan Size Detection - Provides feedback on whether pan size is suitable for the selected element.
- Control Lock - Helps prevent unintended use and makes it easier to clean the control panel
| Specifications | |
| Dimensions | |
| Cutout Depth | 19-5/16 in |
| Cutout Width | 29-1/2 in |
| Depth | 21-5/16 in |
| Height | 3-1/8 in |
| Width | 30-3/4 in |
| Configuration and Overview | |
| ADA Compliant | No |
| Cooktop Type | Standard |
| Fuel Type | Electric Induction |
| Installs Over Built-In Oven | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
| Size | 30 in |
| UL | UL |
| Cooktop Details | |
| Automatic Pan Detection | Yes |
| Cooktop Element Style | Induction |
| Cooktop Surface Color | Black |
| Cooktop Surface Material | Ceramic Glass |
| Downdraft Vent | No |
| Heating Element On Indicator Light | Yes |
| Hot Surface Indicator Light | Yes |
| Left Front Element-Burner Power | 2500W/1800W |
| Left Front Element-Burner Size | 7'' |
| Left Front Element-Burner Type | Bridge |
| Left Rear Element-Burner Power | 2500W/1800W |
| Left Rear Element-Burner Size | 7'' |
| Left Rear Element-Burner Type | Bridge |
| Number of Cooking Element-Burners | 4 |
| Right Front Element-Burner Power | 1800W/1400W |
| Right Front Element-Burner Size | 6'' |
| Right Front Element-Burner Type | Single |
| Right Rear Element-Burner Size | 11'' |
| Right Rear Element-Burner Type | Single |
| Appearance | |
| Digital Display | Yes |
| Electrical | |
| Hz | 60 |
| Power Cord Included | No |
| Controls | |
| Knob Color | NA |
| Location of Controls | Front |
| GDS | |
| GPC Code | 10001951 |
| IsInvoiceUnit | true |
| IsOrderableUnit | true |
| Product Type | EA |
| UDEX | 1100400623 |
| isBaseUnit | true |
| isConsumerUnit | true |
Overview
4-Element Cooktop
Provides four independent cooking surface areas.
2 Elements with Bridge Function
Allows the flexibility to convert two cooking zones into one large cooking zone which provides additional space to accommodate specialty cookware.
12 Heat Level Settings
Provide various levels of heat to fine tune cooking techniques ranging from melting chocolate and simmering a sauce to searing meat or achieving a rapid boil.
Description
This 30-inch induction cooktop uses electromagnetic energy to generate instant heat directly to your cookware without spreading the heat across the entire cooking surface. A bridge function lets you combine the power of two elements into one large cooking zone for specialty cookware such as a griddle or oval pan.
Features
- Performance Boost - Allows you to exceed the maximum heat-level setting for up to 10 minutes, perfect for rapid boiling
- Touch-Activated Controls - Integrate seamlessly into the surface and include a slider for heat-level selection
- Melt and Hold - Uses low power levels for melting delicate ingredients or keeping cooked food warm without scorching.
- Simmer Function - Automatically selects a low power level to help maintain a constant simmer without boiling over.
- Pan Size Detection - Provides feedback on whether pan size is suitable for the selected element.
- Control Lock - Helps prevent unintended use and makes it easier to clean the control panel
Specifications
| Specifications | |
| Dimensions | |
| Cutout Depth | 19-5/16 in |
| Cutout Width | 29-1/2 in |
| Depth | 21-5/16 in |
| Height | 3-1/8 in |
| Width | 30-3/4 in |
| Configuration and Overview | |
| ADA Compliant | No |
| Cooktop Type | Standard |
| Fuel Type | Electric Induction |
| Installs Over Built-In Oven | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov . |
| Size | 30 in |
| UL | UL |
| Cooktop Details | |
| Automatic Pan Detection | Yes |
| Cooktop Element Style | Induction |
| Cooktop Surface Color | Black |
| Cooktop Surface Material | Ceramic Glass |
| Downdraft Vent | No |
| Heating Element On Indicator Light | Yes |
| Hot Surface Indicator Light | Yes |
| Left Front Element-Burner Power | 2500W/1800W |
| Left Front Element-Burner Size | 7'' |
| Left Front Element-Burner Type | Bridge |
| Left Rear Element-Burner Power | 2500W/1800W |
| Left Rear Element-Burner Size | 7'' |
| Left Rear Element-Burner Type | Bridge |
| Number of Cooking Element-Burners | 4 |
| Right Front Element-Burner Power | 1800W/1400W |
| Right Front Element-Burner Size | 6'' |
| Right Front Element-Burner Type | Single |
| Right Rear Element-Burner Size | 11'' |
| Right Rear Element-Burner Type | Single |
| Appearance | |
| Digital Display | Yes |
| Electrical | |
| Hz | 60 |
| Power Cord Included | No |
| Controls | |
| Knob Color | NA |
| Location of Controls | Front |
| GDS | |
| GPC Code | 10001951 |
| IsInvoiceUnit | true |
| IsOrderableUnit | true |
| Product Type | EA |
| UDEX | 1100400623 |
| isBaseUnit | true |
| isConsumerUnit | true |
