Ge Appliances JS760FLDS Ge® 30" Slide-In Electric Convection Range
Fit Guarantee
Replace your old 30" free-standing range with a new 30" slide-in model. GE slide-in ranges are guaranteed for an exact fit or GE Appliances will pay up to $300 toward modifications. See offer criteria and details

12"/9" dual element

Two heating elements in one offer flexibility
True European Convection with Precise Air

Accurate heat circulation ensures evenly baked foods
9"/6" Power Boil element

Produces rapid, powerful heat
Fifth element warming zone

Provides low-heat capability for foods
Fast preheat

Make hot meals in a hurry with less time preheating
Self-clean with Steam Clean option

Clean your oven the way you want
Hidden bake oven interior

Make cleanup easy by eliminating hard-to-reach areas
Smooth-glide storage drawer
Drawer opens and closes easily for instant access and extra storage

- Fit Guarantee
- 12"/9" dual element
- True European Convection with Precise Air
- 9"/6" Power Boil element
- Fifth element warming zone
- Fast preheat
- Self-clean with Steam Clean option
- Hidden bake oven interior
- Smooth-glide storage drawer
CAPACITY | |
Total Capacity (cubic feet) | 5.3 |
FILTER | |
App Filter - Cleaning Type | Steam and Self-Clean |
App Filter - Control Type | Electronic touchpad |
App Filter - Drawer Type | Storage |
App Filter - Cooktop Type | Radiant Smoothtop |
App Filter - Voltage | 240V |
App Filter - Cooking Technology | Convection |
App Filter - Cabinet Width | Cooking 30 in. (Standard) |
App Filter - Product Type | Ranges Slide-In Single Oven |
App Filter - Convection | Yes |
App Filter - Fuel Type | Electric |
APPEARANCE | |
Control Knobs | Black Stainless |
Handle Color | Black Stainless |
Textured Steel Side Panels | Yes |
Oven Door Features | Big View Oven Window Clearview Glass Door |
Color Appearance | Fingerprint Resistant Black Slate |
POWER / RATINGS | |
KW Rating at 208V | 10.2 |
Bake Wattage | 2850W |
KW Rating at 240V | 13.6 |
Convection Wattage | 2500W |
Broiler Wattage | 4000W |
Amp Rating at 208V | 40 |
Amp Rating at 240V | 40 |
WARRANTY | |
Warranty Notes | See written warranty for full details |
Parts Warranty | Limited 1-year entire appliance |
Labor Warranty | Limited 1-year entire appliance |
ACCESSORIES | |
Trim Kit | JXFILLR1DD Optional |
Cooktop Cleaning | Cream Included Sponge |
WEIGHTS & DIMENSIONS | |
Net Weight | 179.0 |
Height to Cooking Surface (in.) | 36 |
Depth Without Handle | 27.375 |
Overall Depth | 28.25 |
Depth with Door Open | 48.25 |
Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
Overall Width | 29.875 |
Overall Height | 37.25 |
Approximate Shipping Weight | 200.0 |
Cabinet Width | 30.0 |
Height to Top of Rear Vent Trim | 37.25 |
FEATURES | |
Oven Cleaning Type | Self-Clean with Steam Clean Option |
Hot Surface Indicator Lights | 1 |
Cooktop Burner Type | Radiant Smoothtop |
Cooking System | True European Convection with Precise Air |
Oven Interior | 1 Incandescent Light Black |
Element - Center | 6' 100W Warming Zone |
Element - Left Front | 9'/6' 3100W Power Boil |
Oven Rack Features | 3 Oven Racks 6 Rack Positions |
Melt Setting | Yes |
Oven Features | 4-Pass Bake Element 8-Pass Broil Element Hidden Bake |
Optional Accessories | WB48X20881 Roller Rack |
Fuel Type | Electric |
Cooking Technology | Convection |
Cooktop Surface | Gray |
Configuration | Range with Storage Drawer |
Control Type | Digital Temperature Display Electronic Touchpads |
Element - Right Front | 12'/9' 3000W |
Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off with Override Auto Recipe Conversion Auto Self Clean Certified Sabbath Mode Control Lock Capability Convection Bake Delay Bake Option (Time Bake) Delay Clean Option Electronic Clock & Kitchen Timer Fast Preheat Hi / Low Broil Oven 'ON' Light Self-Clean Cool Down Time Display Self-Cleaning Cycling Light |
Product Type | Slide-In Single Oven |
Drawer Type | Storage |
Interior Oven Light | 1 Halogen Preheat Notification |
Cooktop Type | Radiant Smoothtop |
Control Location | Front |
Element - Right Rear | 6' 1200W |
Storage Drawer Features | Removable Full-Width |
Heating Element 'ON' Indicator Light | 1 |
Element - Left Rear | 6' 1200W |
CES700M CES750M CHS900M CHS90XM JB250 JB258 JB625 JB645 JB655 JB700 JB750 JB755 JBS60 JS645 JS660 JS760 PB911 PB930 PHB920 PHS930 PS960
