Friedrich SH20M30B Hazardgard Sh20M30B

Friedrich SH20M30B Hazardgard Sh20M30B

Proven Performance In The Most Challenging Environments Ul Listed For Class 1, Divi... Read more...

x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    THIS ITEM QUALIFIES FOR FREE DELIVERY!

    List Price: $5,709.00
    Our Price: $4,849.00
    You save: $860.00 (15%)
    EXTENDED PROTECTION

    5 year plan

    $414.99

    3 year plan

    $236.99
    Shipping calculated at checkout.

    Availability : Temporarily Out Of Stock
    Secure your place in line for this item. As it becomes available it will be fulfilled on a first come first serve basis. We are doing everything we can to expedite orders.

    View full details

    x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    Friedrich SH20M30B Hazardgard Sh20M30B
    Friedrich SH20M30B Hazardgard Sh20M30B
    Proven Performance In The Most Challenging Environments Ul Listed For Class 1, Division 2, Groups A, B, C And D (Bull)Certified In Accordance With Isa 12.12.01 And Nfpa 70 (National Electric Code), Ansi/Ul 484 Room Air Conditioners (Bull)Ksa Registered And Tested In Accordance With Saso 2681 For More Than Three Decades, Global Industry And High-Tech Leaders Have Trusted Hazardgard To Provide Commercial-Grade Cooling Under The Harshest Conditions. You'Ll Find Durable, Reliable Hazardgard Room Air Conditioners On Oil Rigs And Military Bases, In Manufacturing Companies And Processing Plants - Anywhere Hazardous Materials Are Used. Hazardgard Is Specifically Designed To Cool Spaces Where Volatile, Flammable Liquids And Gases Are Used, Within Enclosed Systems Or Containers, Or Under Extreme Temperatures. Watch The Hazardgard Product Video Temperature Classification Electrical Equipment, Like Hazardous Location Air Conditioners, That May Be Exposed To Specific, Hazardous Gases Or Vapors In The Area Where It Will Be Used, Cannot Reach Temperatures That Exceed 80% Of The Auto-Ignition Temperature Of Those Gases Or Vapors. Hazardgard Has A T4 Rating Which Means That It'S Surface Temperature Should Not Exceed 135(Degree)C Or 275(Degree)F. (Note: 50/60Hz Model Listed As T4A For Surface Temperatures To 120(Degree) C/248(Degree) F). Electrical Equipment Label Temperature (C) Temperature (F) T1 450(Degree)C 842(Degree)F T2 300(Degree)C 572(Degree)F T2A 280(Degree)C 536(Degree)F T2B 260(Degree)C 500(Degree)F T2C 230(Degree)C 446(Degree)F T2D 251(Degree)C 483.8(Degree)F T3 200(Degree)C 392(Degree)F T3A 180(Degree)C 356(Degree)F T3B 165(Degree)C 329(Degree)F T3C 160(Degree)C 320(Degree)F T4 135(Degree)C 275(Degree)F T4A 120(Degree)C 248(Degree)F T5 100(Degree)C 212(Degree)F T6 85(Degree)C 185(Degree)F The Above Chart Illustrates That 200(Degree)C Is The Maximum Surface Temperature For Any Electrical Equipment With A Temperature Classification Of T3 Or Higher. Auto-Ignition Temperatures (Vapors And Gases) The Maximum Temperature At Which A Liquid, Gas Or Vapor Can Ignite Without The Help Of An Outside Source Of Heat Is The Auto-Ignition Temperature. These Temperatures Are Determined Based On Conditions During Laboratory Testing. For Example: Gas Temperature (C) Temperature (F) Methane 580(Degree)C 1076(Degree)F Hydrogen 560(Degree)C 1040(Degree)F Propane 493(Degree)C 919.4(Degree)F Ethylene 425(Degree)C 797(Degree)F Acetylene 305(Degree)C 581(Degree)F Naphtha 290(Degree)C 554(Degree)F Some Surfaces, Like That Of A High-Pressure Steam Pipe, Can Have A Greater Auto-Ignition Temperature Than Certain Mixtures Of Fuel And Air. Auto-Ignition Temperatures (Dust) As Seen On The Chart Below, The Auto-Ignition Temperature Of Dust Is Typically Greater Than The Auto-Ignition Temperature Of Vapors And Gases. Such Examples Include: Substance Temperature (C) Temperature (F) Sugar 460(Degree)C 860(Degree)F Wood 340(Degree)C 644(Degree)F Flour 340(Degree)C 644(Degree)F Grain Dust 300(Degree)C 572(Degree)F Tea 300(Degree)C 572(Degree)F Durable, Reliable And Safe Robust Engineering, Commercial-Grade Components And Extensive Field Testing Show That Hazardgard Provides The Durability And Safety Required In Hazardous Locations. See The Complete Features List For Details On What Makes Hazardgard The Best Choice In Tough Operating Environments. Harsh Environments Demand Hazardgard Hazardgard Is Ideal For: (Ul)(Li)Offshore Oil Rigs, Onshore Oil Company Offices And Refineries(/Li)(Li)Petrochemical Sites And Propane Fill-Up Stations(/Li)(Li)Paint And Varnish Storage Or Processing Plants(/Li)(Li)Grain Alcohol Processors Or Storage Sites(/Li)(Li)Plant Areas Using Strong Solvents Or Chemicals(/Li)(Li)Munitions Plants Or Armories(/Li)(


      Model SH20M30B
      Cooling Btu 19000/ 19000
      Heating Btu n/a
      EER 9.7/ 9.6
      Volts Rated 230/ 208v
      ENERGY STAR® Qualified No
      Unit Height 17 15/16'
      Unit Width 25 15/16'
      Unit Depth 29'
      Unit Dimensions
      Height 17 15/16'
      Width 25 15/16'
      Depth 29'
      Window Dimensions
      Height 17 15/16'
      Width 27 3/8'
      Depth 42'
      In-Wall Dimensions
      Height 18 3/16'
      Width 26 3/16'
      Depth 7 3/8'
      Additional Measurement Information
      Depth to Louvers 7 3/8'
      Sleeve Size M
      Detailed Electrical Information
      Voltage 230/208
      Cooling Amps 8.5/9.4
      Heating Amps n/a
      Air Circulation 375 cubic feet per minute
      Est. Yearly Operating Costs n/a
      Moisture Removal 5.5 pints per hour
      Net Weight 166 lbs
      Shipping Weight 170 lbs
