Superior Capture Over the Competition

The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
Bright Halogen Lighting

The warm glow of powerful, multi-level halogen lighting provides full illumination over and around cooktop areas.
Control. Just the Way You Want it.

Hidden on/off rocker switches control blower speeds and light levels.
EZ1 Installation System

We watched countless installations as we set out to simplify and accellerate the process. The result is a two-bracket system that holds the hood for you while you make electrical and ducting connections. It's easy and fast - up to 50% less installation time.
Functional Filtration for Your Sense of Style

Dishwasher-safe, micro-mesh filters provide efficient grease removal.
- Superior Capture Over the Competition
- The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
- Bright Halogen Lighting
- The warm glow of powerful, multi-level halogen lighting provides full illumination over and around cooktop areas.
- Control. Just the Way You Want it.
- Hidden on/off rocker switches control blower speeds and light levels.
- EZ1 Installation System
- We watched countless installations as we set out to simplify and accellerate the process. The result is a two-bracket system that holds the hood for you while you make electrical and ducting connections. It's easy and fast - up to 50% less installation time.
- Functional Filtration for Your Sense of Style
- Dishwasher-safe, micro-mesh filters provide efficient grease removal.
- Superior Capture Over the Competition
- The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
- Bright Halogen Lighting
- The warm glow of powerful, multi-level halogen lighting provides full illumination over and around cooktop areas.
Color Finish | Stainless Steel |
CFM | 250 Max high - 110 Min normal |
Sones | 5.0 Max high - 1.5 Min normal |
Product Depth | 22' |
Product Height | 5' |
Product Width | 35-7/8' |
Light Number Of Levels | 2 |
Light Color Temp | 3000 K |
Light Lumens | 450/module |
Light Type | Halogen |
Nightlight Or Nightlight Setting | No |
Light Bulb Wattage | 50W |
Light Bulb Recommended Type | GU10 |
Light Bulbs Included | Yes |
Light Bulb Quantity | 2 |
Filter Quantity | 2 |
Boost Mode | No |
Heat Sentry® - Temperature Sensor | No |
Filter Type | Micro Mesh |
Motor Number Of Speeds | 2 |
Built In Timer | No |
Remote Operation Capable | No |
ADA Compliance | Yes |
Damper Included | Yes |
Non-ducted Filter Included | No |
Amperage | 1.4 |
Rated Voltage | 120 |
Wattage | 168 |
Switch Control Type | Rocker |
Non-Ducted Recirculation Capable | Convertible built-in |
Warranty | 1 Year |
UL Listed | Yes |
Duct Connector Size | 3-1/4' x 10' or 7' Round |
Duct Direction | Horizontal/Vertical |
Duct Shape | Rectangular or Round |
Duct Diameter | 7' |
Duct Height Rectangular | 3-1/4' |
Duct Width Rectangular | 10' |
HVI Certified | Yes |
ENERGY STAR® certified product | No |
Alta BQDD1, BQLA1, BQSJ1, EQLD1 Family Range Hoods

Broan Alta BQSJ1, BQDD1 Single Blower Under Cabinet Range Hood Installation

Broan EZ1 Installation System Features and Benefits
Captur Shadowgraph Broan

Cleaning a Range Hood Filter

Indoor Air Quality: Passions

Older Homes and Indoor Air Quality

Proper Use of a Range Hood

Proper Ventilation Equals a Healthy Home

Range Hoods Reinvented

Spot Ventilation Can Improve the Indoor Air Quality in Your Home

Overview
Superior Capture Over the Competition

The Broan Captur exhaust ventilation system provides the fastest air flow management and filtration in its class for better performance, quieter operation and less energy use.
Bright Halogen Lighting

The warm glow of powerful, multi-level halogen lighting provides full illumination over and around cooktop areas.
Control. Just the Way You Want it.

Hidden on/off rocker switches control blower speeds and light levels.
EZ1 Installation System

We watched countless installations as we set out to simplify and accellerate the process. The result is a two-bracket system that holds the hood for you while you make electrical and ducting connections. It's easy and fast - up to 50% less installation time.
Functional Filtration for Your Sense of Style

Dishwasher-safe, micro-mesh filters provide efficient grease removal.
Description
Features
Specifications
Color Finish | Stainless Steel |
CFM | 250 Max high - 110 Min normal |
Sones | 5.0 Max high - 1.5 Min normal |
Product Depth | 22' |
Product Height | 5' |
Product Width | 35-7/8' |
Light Number Of Levels | 2 |
Light Color Temp | 3000 K |
Light Lumens | 450/module |
Light Type | Halogen |
Nightlight Or Nightlight Setting | No |
Light Bulb Wattage | 50W |
Light Bulb Recommended Type | GU10 |
Light Bulbs Included | Yes |
Light Bulb Quantity | 2 |
Filter Quantity | 2 |
Boost Mode | No |
Heat Sentry® - Temperature Sensor | No |
Filter Type | Micro Mesh |
Motor Number Of Speeds | 2 |
Built In Timer | No |
Remote Operation Capable | No |
ADA Compliance | Yes |
Damper Included | Yes |
Non-ducted Filter Included | No |
Amperage | 1.4 |
Rated Voltage | 120 |
Wattage | 168 |
Switch Control Type | Rocker |
Non-Ducted Recirculation Capable | Convertible built-in |
Warranty | 1 Year |
UL Listed | Yes |
Duct Connector Size | 3-1/4' x 10' or 7' Round |
Duct Direction | Horizontal/Vertical |
Duct Shape | Rectangular or Round |
Duct Diameter | 7' |
Duct Height Rectangular | 3-1/4' |
Duct Width Rectangular | 10' |
HVI Certified | Yes |
ENERGY STAR® certified product | No |
