Broan 153001 Broan® Elite 30-Inch Under-Cabinet Slide-Out Range Hood W/ Light, White
The Slim-Line Style Of The Broan 153001 30 In. Silhouette Slide Out Range Hood In Brushed Alumin... Read more...
SKU:153001
UPC:055321550031
The Slim-Line Style Of The Broan 153001 30 In. Silhouette Slide Out Range Hood In Brushed Aluminum Merges Perfectly Into The Design Of Today'S Contemporary Kitchen. The Unseen Advantages Include The Quiet, Powerful Performance Of The 300 Cfm Dual Centrifugal Blower System. The Blower And Light Automatically Turn On When You Slide Out The Clear Glass Visor And Shut Off When Pushed In. When Activated The Unit Will Automatically Remember The Last Fan Setting You Selected.
- Easy to use slide control automatically recalls last setting used
- Optional (Sold Seperately), Optional (Sold Separately), Optional (Sold Separately), Optional (Sold Separately)
- Ducted vertically through 3-1/4 x 10 ductwork; Damper/duct connector included
- Foam filter (included) is washable for easy maintenance
- 24 in. fluorescent light with prismatic glass lens provides bright, even cooktop lighting (bulb not included)
- Mounts into a full sized cabinet above the cooktop with only a slim, sliding glass drawer visible
| Filter Type | MicroFoam |
| Heat Sentry | No |
| HVI Certified | Yes |
| Lighting Type | Fluorescent |
| UL Listed | Yes |
| ADA Compliance | No |
| Damper Included | No |
| ENERGY STAR® certified | No |
| Light Bulbs Included | No |
| Light Levels | 1 |
| Nightlight Or Nighlight Setting | No |
| Ductless Recirculation Capable | No |
| Ductless Filter Or Kit Included | No |
| Remote Operation Capable | No |
| Speed Levels | Variable |
| Rated Voltage | 120 |
| Boost Mode | No |
| Color Finish | White |
| Rated Amps | 3.7 |
| Product Height | 10-1/2' |
| Product Width | 30' |
| Built-In Timer | No |
| CFM | 300 |
| Duct Direction | Vertical |
| Bulb (Recommended Type) | F20T12 Fluorescent |
| Manufacturer Warranty | 1 Year |
| Wattage | 444 |
Broan Universal Make-Up Air Damper
Broan-NuTone Range Hood & Ventilation Fans Tip - Check Terminations of Ventilation Ducts
Can I install a range hood without venting it? - Danny Lipford
Cleaning a Range Hood Filter
Does an Over the Range microwave provide adequate Capture? - Danny Lipford
Give Your Kitchen A 72 Hour Facelift
How do I determine the size of the range hood I need? - Danny Lipford
How To Ventilate The Whole House
Importance of a Range Hood for Indoor Air Quality
Is there any regular maintenance needed on my range hood? - Danny Lipford
Island Range Hoods for Kitchen Upgrades - Danny Lipford
Kitchen Renovation Includes Adding Range Hood with Danny Lipford
Proper Use of a Range Hood
Proper Ventilation Equals a Healthy Home
Residential Kitchen Make-Up Air Webinar September 24, 2013
What are CFMs? - Danny Lipford
Description
The Slim-Line Style Of The Broan 153001 30 In. Silhouette Slide Out Range Hood In Brushed Aluminum Merges Perfectly Into The Design Of Today'S Contemporary Kitchen. The Unseen Advantages Include The Quiet, Powerful Performance Of The 300 Cfm Dual Centrifugal Blower System. The Blower And Light Automatically Turn On When You Slide Out The Clear Glass Visor And Shut Off When Pushed In. When Activated The Unit Will Automatically Remember The Last Fan Setting You Selected.
Features
- Easy to use slide control automatically recalls last setting used
- Optional (Sold Seperately), Optional (Sold Separately), Optional (Sold Separately), Optional (Sold Separately)
- Ducted vertically through 3-1/4 x 10 ductwork; Damper/duct connector included
- Foam filter (included) is washable for easy maintenance
- 24 in. fluorescent light with prismatic glass lens provides bright, even cooktop lighting (bulb not included)
- Mounts into a full sized cabinet above the cooktop with only a slim, sliding glass drawer visible
Specifications
| Filter Type | MicroFoam |
| Heat Sentry | No |
| HVI Certified | Yes |
| Lighting Type | Fluorescent |
| UL Listed | Yes |
| ADA Compliance | No |
| Damper Included | No |
| ENERGY STAR® certified | No |
| Light Bulbs Included | No |
| Light Levels | 1 |
| Nightlight Or Nighlight Setting | No |
| Ductless Recirculation Capable | No |
| Ductless Filter Or Kit Included | No |
| Remote Operation Capable | No |
| Speed Levels | Variable |
| Rated Voltage | 120 |
| Boost Mode | No |
| Color Finish | White |
| Rated Amps | 3.7 |
| Product Height | 10-1/2' |
| Product Width | 30' |
| Built-In Timer | No |
| CFM | 300 |
| Duct Direction | Vertical |
| Bulb (Recommended Type) | F20T12 Fluorescent |
| Manufacturer Warranty | 1 Year |
| Wattage | 444 |
