Summit FS407LBIFRADA Ada Compliant 20" Wide Built-In Undercounter All-Freezer For General Purpose Use, -20 C Capable With A Lock And Ss Door Frame For Slide-In Custom Panels
Summit FS407LBIFRADA Ada Compliant 20" Wide Built-In Undercounter All-Freezer For General Purpose Use, -20 C Capable With A Lock And Ss Door Frame For Slide-In Custom Panels
SKU: FS407LBIFRADA
UPC: 761101036717
32" Height Fits Under Lower Ada Compliant Counters Flexible Design Allows Built-In Or Freestandin... Read more...
x
Installation and Removal
x
When Will I Get My Order?
x
THIS ITEM QUALIFIES FOR FREE DELIVERY!
Our Price: $1,014.69
EXTENDED PROTECTION
3 year plan
$120.995 year plan
$228.99Shipping calculated at checkout.
Couldn't load pickup availability
x
Installation and Removal
x
When Will I Get My Order?
x
Summit FS407LBIFRADA Ada Compliant 20" Wide Built-In Undercounter All-Freezer For General Purpose Use, -20 C Capable With A Lock And Ss Door Frame For Slide-In Custom Panels
32" Height Fits Under Lower Ada Compliant Counters Flexible Design Allows Built-In Or Freestanding Use In 20" Wide Spaces -20 C Capable With Interior Slide-Out Drawers For Easy Storage Factory Installed Lock Provides Security You Can Count On Slide Your Own Panel Into The Door Frame For An Easy Custom Look Accucold By Summit Appliance Fs407Lbiada Series Offers A Quality Selection Of 20" Wide General Purpose All-Freezers For Built-In Use Under Ada Compliant Counters. The Fs407Lbifrada Is A White All-Freezer With Manual Defrost Operation And 2.8 Cu.Ft. Capacity. Four Pull-Out Drawers With Clear Fronts Offer Convenient Storage Solutions. The Adjustable Thermostat Is Located In The Rear Of The Model. A Two-Piece Stainless Steel Door Frame Lets You Slide In Your Own Door Panel To Create A Custom Look. This Model Has A Reversible Door With A Factory-Installed Lock, Top-Mounted For Added Convenience. Sized At 32" High And Just Under 20" Wide, The Fs407Lbifrada Is Designed To Fit Under Lower Ada Compliant Counters. This Unit Can Be Used Built-In Or Freestanding And Can Be Perfectly Paired With Our Auto Defrost Ff511Lbifrada All-Refrigerator.
- ADA compliant: 32" high to fit under lower ADA compliant counters
- Slim 20" width: 2.8 capacity inside a slim footprint
- Built-in capable: Make the best use of space by installing your appliance under the counter
- Fully finished white cabinet: Allows the unit to be used freestanding
- Factory installed lock: Top-mounted for convenient security
- Stainless steel door frame: Two-piece "U"-shaped door frame accepts slide-in custom panels (panel size: 19 1/4" W x 31 1/4" H at up to 1/4" thick)
- Reversible door: Keep your options flexible with a reversible door that is easy to switch when your arrangement changes
- Manual defrost: Efficient performance with reliable temperature stability
- -20 capable: Low temperature capability ideal for certain sensitive items
- Pull-out drawers: Four clear baskets for convenient and separated storage
- Adjustable thermostat: Rear mounted to prevent accidental adjustments
- Flat door liner: Easy to clean, with more depth for storage
- Matching refrigerator available: Pair with FF511LBIFRADA for a complete ADA compliant set
- 100% CFC Free: Environmentally friendly design with no ozone-damaging chemicals
| Overview | |
| Height of Cabinet | 32.0' (81 cm) |
| Height to Hinge Cap | 32.5' (83 cm) |
| Width | 19.25' (49 cm) |
| Depth | 21.38' (54 cm) |
| Depth with door at 90° | 39.5' (100 cm) |
| Capacity | 2.8 cu.ft. (79 L) |
| Defrost Type | Manual |
| Door | Panel-Ready |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.6 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 64.0 lbs. (29 kg) |
| Shipping Weight | 67.0 lbs. (30 kg) |
| Estimated Time to Ship | 2 to 4 days |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| Freezer | |
| Door Swing | RHD |
| Reversible | Yes |
| Interior Height | 26.38' (67 cm) |
| Interior Width | 14.0' (36 cm) |
| Interior Depth | 16.75' (43 cm) |
| Thermostat Type | Dial |
| Refrigerant Type | R134a |
| Refrigerant Amount | 3.0 oz. |
| High Side PSI | 210.0 |
| Low Side PSI | 105.0 |
| Level Legs | 2 |
| Interior Drawers | Yes |
| Drawers Qty | 4 |
| Exterior | |
| DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout | DL2 - Factory installed NIST calibrated data logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout |
| TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order | PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices |
| DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management | Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations |
| Extra key Extra keys available for purchase | SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option |
| LHD - Left hand door swing Door reversal to left hand swing | Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles. |
| HUM - Humidity sensor Humidity sensor with min/max readout | DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac |
| Lock | |
| KEYPAD Battery-powered keypad door lock installed for keyless security | AC Keypad Keypad door lock powered by appliance power cord for keyless security |
