Summit FF7LBIIFADA Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Or Commercial Use, Auto Defrost W/Lock And Integrated Door Frame For Overlay Panels

Summit FF7LBIIFADA Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Or Commercial Use, Auto Defrost W/Lock And Integrated Door Frame For Overlay Panels

THIS ITEM QUALIFIES FOR FREE DELIVERY!

Call us at (800) 288-1647 for expert assistance in finding the perfect alternative.

Shipping calculated at checkout.
View full details

When Will I Get My Order?

x

Summit FF7LBIIFADA Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Or Commercial Use, Auto Defrost W/Lock And Integrated Door Frame For Overlay Panels
Summit FF7LBIIFADA Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Or Commercial Use, Auto Defrost W/Lock And Integrated Door Frame For Overlay Panels

32" Height Allows Installation Under Lower Ada Compliant Counters Commercially Approved For Use In Foodservice Establishments Flexible Design Allows Built-In Or Freestanding Use In 24" Spaces Factory-Installed Lock Provides Security You Can Count On Customizable Door Front Accepts Full Overlay Panels For A Seamless Look That Can Blend Into Cabinetry Automatic Defrost Ensures Minimum User Maintenance Deep Shelf Space Accommodates Large Trays Made In Europe Accucold By Summit Appliance Offers A Wide Range Of All-Refrigerators For General Purpose Storage. The Commercially Listed Ff7Biada Series Features 24" Wide All-Refrigerators Designed For Built-In Installation Under Lower Ada Compliant Counters. The Ff7Lbiifada Is A 32" High All-Refrigerator With A Full 5.5 Cu.Ft. Capacity Inside A Slim 24" Footprint. The Front-Breathing Design Allows Built-In Use Under Counters, While The Fully Finished Cabinet Also Lets This Unit Be Used Freestanding. This Model Has A White Cabinet. The Door Includes A Factory Installed Lock And An Integrated Stainless Steel Frame To Accept Overlay Panels For A Custom Look. Users Provide Their Own Handle. Inside, The Ff7Lbiifada Utilizes Low Maintenance Automatic Defrost Operation. Our Unique "Hidden" Evaporator Is Set Behind The Rear Wall To Create A Seamless, Easy-To-Clean Interior That Also Maximizes Shelf Space. This Unit Has A Flat Door Liner That Allows It To Accept Larger Trays (Up To 19 1/2" X 16"). Adjustable Wire Shelves Allow Users To Reconfigure The Interior To Accommodate A Variety Of Sizes. The Interior Light Is Controlled By An On/Off Rocker Switch Located Behind The Thermostat Dial. The Ff7Lbiifada Is Etl-S Listed To Nsf-7 Standards For Use In Commercial Establishments. For More Finish Options, Browse The Entire Ff7Biada Series. Note: This Unit Is Designed For General Purpose Or Commercial Applications And Does Not Meet Doe Energy Standards For Residential Use.


  • ADA compliant: 32" height to fit under lower ADA compliant counters
  • Commercially approved: ETL-S listed to NSF-7 Standards for use in commercial establishments
  • Slim undercounter dimensions: Less than 24 inches wide with a full 5.5 c.f. capacity
  • Built-in capable: Make the best use of space by installing your appliance under the counter and flush with other cabinets
  • Factory installed lock: Keyed lock for a secure interior
  • Integrated door frame: Customize the front by mounting an overlay panel over the door; seamless look can blend into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
  • Automatic defrost: Reduced user maintenance with automatic defrost
  • One piece interior liner: Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
  • Hidden evaporator: Cold wall design with hidden evaporator and seamless interior
  • Adjustable shelves: Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
  • Deep shelf space: Interior accommodates large trays up to 19 1/2" x 15 1/2"
  • Adjustable thermostat: Dial thermostat located inside for easy temperature management
  • Interior light on rocker switch: Turn the light on when you need it and off when you're done with a convenient rocker switch
  • Fully finished white cabinet: Allows the refrigerator to be used freestanding
  • 100% CFC free: Environmentally friendly design without ozone-damaging chemicals

Overview
Height of Cabinet 32.0' (81 cm)
Height to Hinge Cap 32.25' (82 cm)
Width 23.63' (60 cm)
Depth 23.5' (60 cm)
Depth with door at 90° 45.63' (116 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door Panel-Ready
Cabinet White
US Electrical Safety UL
Canadian Electrical Safety ULC
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 100.0 lbs. (45 kg)
Shipping Weight 105.0 lbs. (48 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R134a
Refrigerant Amount 1.8oz.
High Side PSI 285.0
Low Side PSI 88.0
Level Legs Qty 4
Interior Light Yes
Dimensions
Interior Height 26.25' (67 cm)
Interior Width 21.0' (53 cm)
Interior Depth 17.75' (45 cm)
Compressor Step Height 5.5' (14 cm)
Compressor Step Width 21.0' (53 cm)
Compressor Step Depth 5.5' (14 cm)
Exterior
DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix
HUM - Humidity sensor Humidity sensor with min/max readout SSK Stainless steel kickplate factory installed
Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles. LHD - Left hand door swing Door reversal to left hand swing
Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management
ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar. SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option
Extra key Extra keys available for purchase TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices DL2 - Factory installed NIST calibrated data logger USB data logger with user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Extra key for IF door Extra key for select IF (panel-ready) units DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Interior
FC - Internal Fan Internal fan for even temperature distribution throughout the unit interior FCGP internal fan with gel packs Internal fan with gel packs included for a stabilized interior
LockBox24 - Interior locking compartment Interior lift up compartment with combination lock for use in ARS, ARG, FF7, and FFAR10 models
Lock
AC Keypad Keypad door lock powered by appliance power cord for keyless security KEYPAD Battery-powered keypad door lock installed for keyless security
