Summit AL750BIFR Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Use, Auto Defrost W/Ss Door Frame For Panel Inserts And White Cabinet

Summit AL750BIFR Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Use, Auto Defrost W/Ss Door Frame For Panel Inserts And White Cabinet

32 Inch Height Fits Under Lower Ada Compliant Counters Flexible Design Allows Built-In Or Freesta... Read more...

x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    THIS ITEM QUALIFIES FOR FREE DELIVERY!

    Our Price: $1,259.17
    EXTENDED PROTECTION

    3 year plan

    $120.99

    5 year plan

    $228.99
    Shipping calculated at checkout.

    Availability : Temporarily Out Of Stock
    Secure your place in line for this item. As it becomes available it will be fulfilled on a first come first serve basis. We are doing everything we can to expedite orders.

    View full details

    x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    Summit AL750BIFR Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Use, Auto Defrost W/Ss Door Frame For Panel Inserts And White Cabinet
    Summit AL750BIFR Ada Compliant Built-In Undercounter All-Refrigerator For General Purpose Use, Auto Defrost W/Ss Door Frame For Panel Inserts And White Cabinet
    32 Inch Height Fits Under Lower Ada Compliant Counters Flexible Design Allows Built-In Or Freestanding Use In 24" Spaces Stainless Steel Door Frame Accepts Slide-In Panels For A Custom Look Automatic Defrost Ensures Minimum User Maintenance Deep Shelf Space Accommodates Large Trays Full 5.5 Cu.Ft. Capacity Inside A Convenient 24" Footprint Made In Europe Accucold By Summit Appliance Offers A Wide Range Of All-Refrigerators For General Purpose Storage. The Al750Bi Series Features 24" Wide All-Refrigerators Designed For Built-In Installation Under Lower Ada Compliant Counters. The Al750Bifr Is A 32" High All-Refrigerator With A Full 5.5 Cu.Ft. Capacity Inside A Slim 24" Footprint. The Front-Breathing Design Allows Built-In Use Under Counters, While The Fully Finished Cabinet Also Lets This Unit Be Used Freestanding. This Model Has A White Cabinet. The Reversible Door Includes A Two-Piece Stainless Steel Frame Designed To Accept Slide-In Panel Inserts For A Custom Look (Panel Size: 23" W X 28" H At Up To 1/4" Thick). A Stainless Steel Handle Is Included. Inside, The Al750Bifr Utilizes Low Maintenance Automatic Defrost Operation. Our Unique "Hidden" Evaporator Is Set Behind The Rear Wall To Create A Seamless, Easy-To-Clean Interior That Also Maximizes Shelf Space. This Unit Has A Flat Door Liner That Allows It To Accept Larger Trays (Up To 19 1/2" X 16"). Adjustable Wire Shelves Allow Users To Reconfigure The Interior To Accommodate A Variety Of Sizes. The Interior Light Is Controlled By An On/Off Rocker Switch Located Behind The Thermostat Dial. For More Finish Options, Browse The Entire Al750Bi Series. Note: This Unit Is Designed For General Purpose, Medical, Or Commercial Applications And Does Not Meet Doe Energy Standards For Residential Use.

    • ADA compliant: 32 inch height fits under standard ADA counters
    • Slim undercounter dimensions: Less than 24 inches wide with a full 5.5 c.f. capacity
    • Built-in capable: Make the best use of space by installing your appliance under the counter and flush with other cabinets
    • Fully finished white cabinet: Allows the unit to be used freestanding
    • Stainless steel door frame: Slide a panel into this two-piece U-shaped frame to match your unit to other cabinets (panel size: 23" W x 28" H at up to 1/4" thick)
    • Professional handle: Stainless steel handle can be reversed with door swing
    • Reversible door: User-reversible door swing for added flexibility
    • Automatic defrost: Reduced user maintenance with automatic defrost operation
    • Hidden evaporator: Cold wall design with hidden evaporator and seamless interior
    • One piece interior liner: Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
    • Adjustable shelves: Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
    • Flat door liner: An easy-to-clean flat liner accepts large trays
    • Deep shelf space: Interior accommodates large trays up to 19 1/2" x 15 1/2"
    • Interior light on rocker switch: Turn the light on when you need it and off when you're done with a convenient rocker switch
    • Adjustable thermostat: Dial thermostat located inside for easy temperature management
    • 100% CFC free: Environmentally friendly design without ozone-damaging chemicals

    Overview
    Height of Cabinet 32.0' (81 cm)
    Height to Hinge Cap 32.25' (82 cm)
    Width 23.63' (60 cm)
    Depth 23.5' (60 cm)
    Depth with Handle 25.13' (64 cm)
    Depth with door at 90° 45.63' (116 cm)
    Capacity 5.5 cu.ft. (156 L)
    Defrost Type Automatic
    Door Panel-Ready
    Cabinet White
    US Electrical Safety UL
    Canadian Electrical Safety ULC
    Amps 1.3
    Voltage/Frequency 115 V AC/60 Hz
    Weight 100.0 lbs. (45 kg)
    Shipping Weight 105.0 lbs. (48 kg)
    Estimated Time to Ship 2 to 4 days
    Parts & Labor Warranty 1 Year
    Compressor Warranty 5 Years
    Refrigerator Features
    Door Swing RHD
    Reversible Yes
    Shelf Type Wire
    Shelf Qty 3
    Adjustable Shelves Yes
    Thermostat Type Dial
    Fan Type Exterior
    Refrigerant Type R134a
    Refrigerant Amount 1.8oz.
    High Side PSI 285.0
    Low Side PSI 88.0
    Level Legs Qty 4
    Interior Light Yes
    Dimensions
    Interior Height 26.25' (67 cm)
    Interior Width 21.0' (53 cm)
    Interior Depth 17.75' (45 cm)
    Compressor Step Height 5.5' (14 cm)
    Compressor Step Width 21.0' (53 cm)
    Compressor Step Depth 5.5' (14 cm)
    Exterior
    DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix
    HUM - Humidity sensor Humidity sensor with min/max readout SSK Stainless steel kickplate factory installed
    Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles. LHD - Left hand door swing Door reversal to left hand swing
    ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar. SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option
    Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management
    PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
    DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
    Interior
    FC - Internal Fan Internal fan for even temperature distribution throughout the unit interior FCGP internal fan with gel packs Internal fan with gel packs included for a stabilized interior
    Lock
    AC Keypad Keypad door lock powered by appliance power cord for keyless security KEYPAD Battery-powered keypad door lock installed for keyless security
    L Installed Lock Add a single key lock to the door with the L option
