Summit AL652BBIIF Built-In Undercounter Ada Compliant Refrigerator-Freezer For General Purpose Use, Cycle Defrost W/Dual Evaporator Cooling, Panel-Ready Door, And Black Cabinet

Summit AL652BBIIF Built-In Undercounter Ada Compliant Refrigerator-Freezer For General Purpose Use, Cycle Defrost W/Dual Evaporator Cooling, Panel-Ready Door, And Black Cabinet

x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    THIS ITEM QUALIFIES FOR FREE DELIVERY!

    Our Price: $1,290.76
    EXTENDED PROTECTION

    3 year plan

    $120.99

    5 year plan

    $228.99

    Availability : Temporarily Out Of Stock
    Secure your place in line for this item. As it becomes available it will be fulfilled on a first come first serve basis. We are doing everything we can to expedite orders.

    Shipping calculated at checkout.
    View full details

    x

  • Installation and Removal

    x

    When Will I Get My Order?

    x

    Summit AL652BBIIF Built-In Undercounter Ada Compliant Refrigerator-Freezer For General Purpose Use, Cycle Defrost W/Dual Evaporator Cooling, Panel-Ready Door, And Black Cabinet
    Summit AL652BBIIF Built-In Undercounter Ada Compliant Refrigerator-Freezer For General Purpose Use, Cycle Defrost W/Dual Evaporator Cooling, Panel-Ready Door, And Black Cabinet
    Flexible Design Allows Built-In Or Freestanding Use In 24" Spaces 32" Height For Use Under Lower Ada Compliant Counters Improved Temperature Performance With Our Unique Dual Evaporator Cooling Customizable Door Front Accepts Full Overlay Panels Made In Europe Accucold By Summit Appliance Offers A Wide Range Of Undercounter Refrigeration For General Purpose Storage. The Al650Bi Series Includes Refrigerator-Freezers Designed For Optimum Storage Conditions In Built-In Applications Under Lower Ada Compliant Counters. At 32" High, The Al652Bbiif Can Be Used Built-In Or Freestanding In Ada Compliant Settings. The 24" Footprint Fits Many Popular Cutouts While Offering Over 5 Cu.Ft. Of Storage Capacity. This Model Has A Black Cabinet. The Door Includes An Integrated Stainless Steel Frame Designed To Accept Full Overlay Panels For A Custom Look. Users Provide Their Own Handle. Inside, Our Unique Dual Evaporator System Separately Cools The Refrigerator And Freezer Sections To Ensure Proper Storage Temperature. Cycle Defrost Operation Reduces User Maintenance In The Automatic Defrost Fresh Food Section, With Static Manual Defrost Operation In The Freezer Compartment. Door Storage Provides Easy Access For Tall Bottles And Small Condiments. Additional Features Include Adjustable Glass Shelves, A Clear Crisper, And Automatic Interior Lighting. The Al652Bbiif Has Long Proven Itself To Have One Of The Best Temperature Performance Records In The Industry. To See Additional Finish Options On This Unit, Browse The Full Al650Bi Series. Note: This Unit Is Designed For General Purpose, Medical, Or Commercial Applications And Does Not Meet Doe Energy Standards For Residential Use.

    • ADA compliant: 32 inch height fits under standard ADA counters
    • Slim undercounter dimensions: Less than 24 inches wide to fit tight spaces
    • Built-in capable: Make the best use of space by installing your appliance under the counter and flush with other cabinets
    • Fully finished black cabinet: Allows the unit to be used freestanding
    • Integrated door frame: Customize the front by mounting an overlay panel over the door; seamless look can blend into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
    • Cycle defrost: This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
    • Dual evaporator: Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
    • Adjustable glass shelves: Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
    • Clear crisper: Get the longest life and best taste out of produce by storing greens in a convenient slide drawer
    • Door shelves: Store large bottles right on the door for easy access
    • Interior light: Automatically illuminates when you open the door
    • Adjustable thermostat: Dial thermostat located inside for easy temperature management
    • 100% CFC free: Environmentally friendly design without ozone-damaging chemicals

    Overview
    Height of Cabinet 32.0' (81 cm)
    Height to Hinge Cap 32.25' (82 cm)
    Width 23.63' (60 cm)
    Depth 23.5' (60 cm)
    Depth with door at 90° 45.38' (115 cm)
    Capacity 5.1 cu.ft. (144 L)
    Defrost Type Cycle
    Door Panel-Ready
    Cabinet Black
    US Electrical Safety UL
    Canadian Electrical Safety ULC
    Amps 1.3
    Voltage/Frequency 115 V AC/60 Hz
    Weight 100.0 lbs. (45 kg)
    Shipping Weight 105.0 lbs. (48 kg)
    Estimated Time to Ship 2 to 4 days
    Parts & Labor Warranty 1 Year
    Compressor Warranty 5 Years
    Refrigerator-Freezer
    Door Swing RHD
    Reversible Factory Reversible
    Adjustable Shelves Yes
    Crisper Qty 1
    Crisper Finish Transparent
    Crisper Cover Glass
    Interior Light Yes
    Refrigerator - Interior Height 19.5' (50 cm)
    Refrigerator - Interior Width 20.5' (52 cm)
    Refrigerator - Interior Depth 17.0' (43 cm)
    Refrigerator - Shelf Type Glass
    Refrigerator - Shelf Qty 3
    Refrigerator - Full Door Shelves 3
    Freezer - Interior Height 5.0' (13 cm)
    Freezer - Interior Width 19.0' (48 cm)
    Freezer - Interior Depth 11.5' (29 cm)
    Thermostat Type Dial
    Fan Type Exterior
    Refrigerant Type R134a
    Refrigerant Amount 2.6 oz.
    High Side PSI 285.0
    Low Side PSI 70.0
    Level Legs 4
    Compressor Step Height 7.0' (18 cm)
    Compressor Step Width 20.5' (52 cm)
    Compressor Step Depth 5.0' (13 cm)
    Exterior
    DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
    PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
    SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.
    LHD - Left hand door swing Door reversal to left hand swing Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
    SSK Stainless steel kickplate factory installed HUM - Humidity sensor Humidity sensor with min/max readout
    HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
    Lock
    L-Installed Lock Add a single key lock to the door with the L option KEYPAD Battery-powered keypad door lock installed for keyless security
    AC Keypad Keypad door lock powered by appliance power cord for keyless security AC Keypad Keypad door lock powered by appliance power cord for keyless security
    Interior
    FCGP internal fan with gel packs Internal fan with gel packs included for a stabilized interior FC - Internal Fan Internal fan for even temperature distribution throughout the unit interior
