    Accucold By Summit Appliance Carries A Range Of General Purpose And Medical All-Freezers Designed... Read more...

    This Item Qualifies for Free Delivery!
    Regular price
    Sale price
    Our Price: $1,915.72
    Regular price
    Unit price
    per

    Availability : Delivery Dated Based on Manufacturer Availability

    - +
    Extended protection

    5 year plan

    $359.99

    3 year plan

    $188.99

    Extended Protection

    Purchase an Extended Protection plan that extends the terms of your appliance manufacturer’s warranty for an additional period after the original warranty expires.

    This Protection Plan includes:

    - Full parts and labor coverage during the whole period of the extension plan.
    - Protection for the case of a power surge during both the period of the extension plan and manufacturer’s warranty (click here for details)
    - Food loss protection (click here for details)
    - 24/7 toll-free number for support (1-877-879-6395)

    Installation and Removal
  • Where will services be needed?

    When Will I Get My Order?
    Accucold By Summit Appliance Carries A Range Of General Purpose And Medical All-Freezers Designed For Reliable, Frost-Free Storage Under The Counter. At 24" Wide, The Acf48Wsshv Is Ideally Sized For Many Institutional Or Laboratory Settings. The Front-Breathing Design Allows Built-In Installation, While The Fully Finished Cabinet Also Allows Freestanding Use. The User-Reversible Door Includes A Factory Installed Keyed Lock For Added Security. This Model Comes With A White Cabinet And Stainless Steel Wrapped Door With A Thin Pro Style Handle. It Includes A Hospital Grade Cord With A 'Green Dot' Plug For Added Security In High Traffic Areas. Full Frost-Free Operation Ensures Low Maintenance Operation, With An Internal Fan To Keep The Interior Evenly Cooled From Top To Bottom. A Digital Thermostat Is Located In The Front Kickplate, Letting Users Manage The Temperature Without Having To Open The Door. The Interior Includes Two Removable Steel Shelves. Made In The Usa, The Acf48Wsshv Offers Quality Freezer Storage In A Conveniently Sized And Featured Unit. It Is Etl-S Listed To Nsf-7 Commercial Standards And Meets Ul-471. For This Unit Sized For Use Under Ada Compliant Counters, See The Acf48Wsshvada. Additional Door Finishes Are Available. This Model Can Also Be Paired With The Matching Ff7Lbisshv All-Refrigerator.
    • Slim undercounter dimensions: Sized at less than 24" wide and deep for an easy fit in space-challenged institutions
    • Built-in capable: Front-breathing system allows the unit to be used built-in
    • Frost-free operation: Keyed lock for added security, located towards the top of the door to ensure convenient access
    • Digital temperature control: Electronic controls located in the exterior kickplate for precise temperature management
    • Factory installed lock: Keyed lock offers convenient security
    • Removable shelves: Includes two slide-out shelves made from durable steel
    • Stainless steel wrapped door: 304 grade stainless steel exterior door finish ensures lasting quality and improved sanitation
    • Professional handle: Brushed stainless steel handle with a thin 14mm diameter
    • Hospital grade cord: Secure three-pronged cord for added unit safety
    • Internal fan: Fan-forced cooling ensures the unit is evenly cooled from top to bottom
    • Flat door liner: Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials
    • Foamed-in-place cabinet: Quality design ensures efficiently insulated interior
    • Fully finished white cabinet: Allows the unit to be used freestanding
    • Commercially approved: Design meets UL-471 and is ETL-S listed to NSF-7 commercial standards
    • 100% CFC free: Environmentally friendly design without ozone-damaging chemicals
    Overview
    Height of Cabinet 33.0' (84 cm)
    Height to Hinge Cap 33.5' (85 cm)
    Width 23.63' (60 cm)
    Depth 23.5' (60 cm)
    Capacity 3.1 cu.ft. (88 L)
    Defrost Type Frost-Free
    Door Stainless Steel
    Cabinet White
    US Electrical Safety ETL
    Canadian Electrical Safety ETL-C
    Sanitation ETL-S
    Amps 1.3
    Voltage/Frequency 115 V AC/60 Hz
    Weight 110.0 lbs. (50 kg)
    Shipping Weight 115.0 lbs. (52 kg)
    Parts & Labor Warranty 1 Year
    Compressor Warranty 5 Years
    Freezer
    Door Swing RHD
    Reversible Factory Reversible
    Shelf Type Steel
    Shelf Qty 2
    Thermostat Type Digital
    Fan Type Interior and Exterior
    Refrigerant Type R134a
    Refrigerant Amount 4.2 oz.
    High Side PSI 285.0
    Low Side PSI 70.0
    Level Legs 4
    Interior Drawers Yes
    Temperature Range -5 to 10 F/-20 to -12 C
    Door
    STO-Step-To-Open Door Pedal Step-to-open door pedal allows hands free access to open the door 90 degrees
    Handle
    TBC Copper Towel Bar Handle Upgrade Change this handle to a 12' vertically mounted towel bar style handle made from pure copper for antimicrobial protection TBC Copper Towel Bar Handle Upgrade Change this handle to a 12' vertically mounted towel bar style handle made from pure copper for antimicrobial protection
    Exterior
    Agion Cabinet Exterior cabinet and door treated with Agion silver antimcrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface
    CAS6 6' casters 6' high NSF listed casters Legs to raise unit height 6' high leveling legs
    LHD - Left hand door swing Door reversal to left hand swing ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.
    SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option CAS3 3' casters 3' high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
    PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
    DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac Extra key Extra keys available for purchase
    SSK Stainless steel kickplate factory installed DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
    Lock
    AC Keypad Keypad door lock powered by appliance power cord for keyless security KEYPAD Battery-powered keypad door lock installed for keyless security

    Description

    Accucold By Summit Appliance Carries A Range Of General Purpose And Medical All-Freezers Designed For Reliable, Frost-Free Storage Under The Counter. At 24" Wide, The Acf48Wsshv Is Ideally Sized For Many Institutional Or Laboratory Settings. The Front-Breathing Design Allows Built-In Installation, While The Fully Finished Cabinet Also Allows Freestanding Use. The User-Reversible Door Includes A Factory Installed Keyed Lock For Added Security. This Model Comes With A White Cabinet And Stainless Steel Wrapped Door With A Thin Pro Style Handle. It Includes A Hospital Grade Cord With A 'Green Dot' Plug For Added Security In High Traffic Areas. Full Frost-Free Operation Ensures Low Maintenance Operation, With An Internal Fan To Keep The Interior Evenly Cooled From Top To Bottom. A Digital Thermostat Is Located In The Front Kickplate, Letting Users Manage The Temperature Without Having To Open The Door. The Interior Includes Two Removable Steel Shelves. Made In The Usa, The Acf48Wsshv Offers Quality Freezer Storage In A Conveniently Sized And Featured Unit. It Is Etl-S Listed To Nsf-7 Commercial Standards And Meets Ul-471. For This Unit Sized For Use Under Ada Compliant Counters, See The Acf48Wsshvada. Additional Door Finishes Are Available. This Model Can Also Be Paired With The Matching Ff7Lbisshv All-Refrigerator.

    Features

    • Slim undercounter dimensions: Sized at less than 24" wide and deep for an easy fit in space-challenged institutions
    • Built-in capable: Front-breathing system allows the unit to be used built-in
    • Frost-free operation: Keyed lock for added security, located towards the top of the door to ensure convenient access
    • Digital temperature control: Electronic controls located in the exterior kickplate for precise temperature management
    • Factory installed lock: Keyed lock offers convenient security
    • Removable shelves: Includes two slide-out shelves made from durable steel
    • Stainless steel wrapped door: 304 grade stainless steel exterior door finish ensures lasting quality and improved sanitation
    • Professional handle: Brushed stainless steel handle with a thin 14mm diameter
    • Hospital grade cord: Secure three-pronged cord for added unit safety
    • Internal fan: Fan-forced cooling ensures the unit is evenly cooled from top to bottom
    • Flat door liner: Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials
    • Foamed-in-place cabinet: Quality design ensures efficiently insulated interior
    • Fully finished white cabinet: Allows the unit to be used freestanding
    • Commercially approved: Design meets UL-471 and is ETL-S listed to NSF-7 commercial standards
    • 100% CFC free: Environmentally friendly design without ozone-damaging chemicals

    Specifications

    Overview
    Height of Cabinet 33.0' (84 cm)
    Height to Hinge Cap 33.5' (85 cm)
    Width 23.63' (60 cm)
    Depth 23.5' (60 cm)
    Capacity 3.1 cu.ft. (88 L)
    Defrost Type Frost-Free
    Door Stainless Steel
    Cabinet White
    US Electrical Safety ETL
    Canadian Electrical Safety ETL-C
    Sanitation ETL-S
    Amps 1.3
    Voltage/Frequency 115 V AC/60 Hz
    Weight 110.0 lbs. (50 kg)
    Shipping Weight 115.0 lbs. (52 kg)
    Parts & Labor Warranty 1 Year
    Compressor Warranty 5 Years
    Freezer
    Door Swing RHD
    Reversible Factory Reversible
    Shelf Type Steel
    Shelf Qty 2
    Thermostat Type Digital
    Fan Type Interior and Exterior
    Refrigerant Type R134a
    Refrigerant Amount 4.2 oz.
    High Side PSI 285.0
    Low Side PSI 70.0
    Level Legs 4
    Interior Drawers Yes
    Temperature Range -5 to 10 F/-20 to -12 C
    Door
    STO-Step-To-Open Door Pedal Step-to-open door pedal allows hands free access to open the door 90 degrees
    Handle
    TBC Copper Towel Bar Handle Upgrade Change this handle to a 12' vertically mounted towel bar style handle made from pure copper for antimicrobial protection TBC Copper Towel Bar Handle Upgrade Change this handle to a 12' vertically mounted towel bar style handle made from pure copper for antimicrobial protection
    Exterior
    Agion Cabinet Exterior cabinet and door treated with Agion silver antimcrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface Agion Door Treat the door with Agion silver antimicrobial coating to reduce the growth of bacteria, fungi, molds, and other destructive microbes on appliance surface
    CAS6 6' casters 6' high NSF listed casters Legs to raise unit height 6' high leveling legs
    LHD - Left hand door swing Door reversal to left hand swing ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.
    SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option CAS3 3' casters 3' high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
    PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
    DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac Extra key Extra keys available for purchase
    SSK Stainless steel kickplate factory installed DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
    Lock
    AC Keypad Keypad door lock powered by appliance power cord for keyless security KEYPAD Battery-powered keypad door lock installed for keyless security
