Elica EUM628S1 Umbria Insert Range Hood 28" Wide - 600Cfm
Elica EUM628S1 Umbria Insert Range Hood 28" Wide - 600Cfm
Town Perks Savings
SKU: EUM628S1
UPC: 190603004229
Colors:
Stainless Steelx
Installation and Removal
x
List Price: $969.00
Our Price: $879.00
You save:
$90.00 (9%)
Town Perks Savings:
-$40.00
EXTENDED PROTECTION
3 year plan
$120.995 year plan
$239.00
Available to Order
If a product is marked as 'Available to Order,' it may be in stock, on the way to our warehouse, or may require additional lead time. Once your order is placed, our team will confirm availability and provide an estimated shipping timeline. We'll keep you informed every step of the way.
Couldn't load pickup availability
x
Installation and Removal
x
When Will I Get My Order?
x
Elica EUM628S1 Umbria Insert Range Hood 28" Wide - 600Cfm
Rebates &
Promotions
Town Perks Savings Get $40–$600 in bonus savings on qualifying orders: $40 off $500+, $90 off $1,000+, $200 off $2,000+, $400 off $3,500+, or $600 off $5,000+.
Exclusive savings on qualifying items.
Exclusive savings on qualifying items.
34 Inch Cabinet Insert Range Hood with 600 CFM Internal Blower
Umbria with 28" and 34" width models available and 10 3/₄” depth enables it to be discreetly installed within standard 12” deep cabinetry. Perimeter Aspiration technology helps to achieve Top Performance by delivering more powerful and efficient fume extraction, plus it reduces noise. Umbria is designed for both ducted-out or recirculating installation with an available kit. Now with a snap system that makes it safer and easier to install.
- Perimeter aspiration Hush system Led light Top performance Super easy installation Top or rear outlet
- 600 CFM Internal Blower
- Perimeter Aspiration
- Hush System
- Push Button Controls
- Dishwasher-Safe Mesh Filter
| Warranty | 3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com |
| SHIPPING WEIGHT (kg) | 14.90 |
| NET WEIGHT (kg) | 11.20 |
| CARTON LENGHT (mm) | 837.00 |
| CARTON HEIGHT (mm) | 426.00 |
| CARTON WIDTH (mm) | 389.00 |
| VOLUMEN (M3) | 0.14 |
| SHIPPING WEIGHT | 32.85 |
| NET WEIGHT | 24.69 |
| CARTON LENGHT | 32.95 |
| CARTON HEIGHT | 16.77 |
| CARTON WIDTH | 15.31 |
| COUNTRY OF MANUFACTURE | MX |
| QTY PACKAGE | 1.00 |
| INTENDED APPROVED USE | Residential use |
| Finish | Stainless Steel |
| Color | inox |
| Type of Ventilation | Convertible |
| HOODS FEATURES | Perimeter aspiration Hush system Led light Top performance Super easy installation Top or rear outlet |
| WIDTH (IN) | 28' |
| WIDTH (CM) | 72.00 |
| AIRFLOW (M3/H) | 1020.00 |
| CFM (MAX) | 600.00 |
| db (min) | 35.65 |
| db (max) | 55.00 |
| SONES | 1.7 -6.8 |
| EXHAUST VERSION | Convertible with Kit |
| EXHAUST SIZE | Round 6' |
| DUCT SHAPE | Round |
| EXHAUST LOCATION | Top or Rear |
| RECTANGULAR DUCTH HEIGHT | NA |
| RECTANGULAR DUCT WIDTH | NA |
| Round duct diameter | 6' |
| ELECTRIC (VOLTS) | 120 V/60 Hz |
| AMPERAGE | 15-20 A |
| HERTZ | 60.00 |
| WATTS | 455.00 |
| LIGHTING | LED 2 x 2.1 ww 4000 KK |
| BULB TYPE | LED |
| BULB INCLUDED | YES |
| NUMBER OF LIGHTS | 2.00 |
| BULB WATTS | 2.10 |
| KELVINS | 4000.00 |
| GREASE FILTER TYPE | Dishwasher-Safe, Anodized Aluminum Mesh Filter + Perimeter Aspiration |
| DISHWASHERSAFE FILTER | YES |
| FILTER MATERIAL | Aluminum Mesh |
| BLOWER TYPE | Interior Unit |
| CONTROL TYPE | Stainless Steel Push Button |
| SPEED CONTROL | YES |
| NUMBER OF SPEEDS | 3.00 |
| REMOTE CONTROL | NO |
| POWER SOURCE | Power Cord |
| OUTDOOR USE | NO |
| SMUDGE RESISTANT | NO |
| RECIRCULATION KIT NEEDED | YES |
| CFM REDUCTION | Yes w/kit |
| DIMENSIONS | 72 x 27 x 24 |
| DIMENSIONS inches | 28 1/4' x 10 3/4' x 9 1/2' |
| ADJUSTABLE HEIGHT | NO |
| Minimum Overall Height - Top to Bottom | 9 1/2 |
| Maximum Overall Height - Top to Bottom | 15 3/4' |
| Overall Height - Top to Bottom | 9 1/2 |
| Overall Width - Side to Side2 | 28 1/4 |
| Overall Depth - Front to Back | 10 3/4 |
| Hood Height | 9 1/2 |
| Minimum Compatible Ceiling Height | NA |
| Maximum Compatible Ceiling Height | NA |
| Minimum Height Above Cooktop (ELECTRIC) | 24 |
| Minimum Height Above Cooktop (GAS) | 30 |
| Maximum Height Above Cooktop | 36' |
| Chimney Width - Side to Side | NA |
| Chimney Depth - Front to Back | NA |
| Chimney Height - Top to Bottom | NA |
| RECIRCULATION KIT NUMBER | KIT02770 |
| CHIMNEY EXTENTION NUMBER | NA |
| TELESCOPIC DUCT COVER | - |
| DUCT TRANSITION | - |
| TRANSITION REDUCER KIT | - |
| BACKDRAFT DAMPER | - |
| NON RETURN VALVE | - |
| UPGRADE FILTER | - |
| CFM REDUCTION KIT | KIT0175561 |
| BACKSPLASH KIT | - |
| INTERNAL BLOWER | - |
| INLINE BLOWER | - |
| EXTERNAL BLOWER | - |
| INLINE BLOWER SHELL KIT | - |
| EXTERNAL BLOWER SHELL KIT | - |
| HEAT LAMPS | - |
| SPACER/LINER | KIT02773/KIT02774 |
| WALL MOUNT BRACKET | - |
| HIGH CEILING EXTENSION KIT | - |
| REMOTE CONTROL KIT | - |
| cUL listed | YES |
| UL listed | YES |
| AHAM verified | NO |
| TITLE 24 | NO |
| Prop65 Disclosure | YES |
| ENERGY STAR | NO |
| WIFI CAPABLE | NO |
| COMERCIAL USE APPROVED | NO |
| ADA COMPLIANT | NO |
| APP CAPABLE | NO |
| VENTILATION DIRECTION | HORIZONTAL |
| SMART COMPATIBLE | NO |
| FITLER INDICATOR LIGHT | NO |
| HEAT SENSOR | NO |
| CHAROCAL FILTER | YES |
| VERSION ADVANCES | ADVANCE REAR OUTLET+ |
| CERTIFICADO NOM | NA |
