Frigidaire FDPC4314AS Frigidaire 24" Built-In Dishwasher
Enhanced drying results with MaxDry™
Get an enhanced dry with the MaxDry™ option, which raises the temperature and delivers better results reducing the need for towel drying.
Triple the cleaning power
Give your dishes a more effective clean with our three spray arms, which achieve better water coverage during the cleaning cycle.
Skip Pre-rinsing with DishSense® Sensor Technology
Get better cleaning results with our sensor technology that adjusts cleaning performance based on the soil level of your dishes.
Remove household bacteria with Sanitize Option
Remove 99.9% of common household bacteria with NSF-Certified Sanitize Option.
Quick with 60-minute wash
Quickly clean your dishes in our 60-minute wash cycle.
ENERGY STAR® Certified
Maximize your energy and dollar savings with ENERGY STAR® Certified appliances.
Plus, enjoy an enhanced dry with MaxDry™, which delivers better results reducing the need for towel drying.
This quiet dishwasher (54 dBA) also includes DishSense® Sensor Technology, a sanitize option and is Energy Star® certified.
Triple the cleaning power with three spray arms
Achieve better drying results with the MaxDry™ option
Skip pre-rinsing with sensor technology that adjusts to your load
Dimensions & Capacity Height: 33 1/2“
Width: 24"
Depth: 25"
- 14 Place Setting Capacity
- Automatic Temperature Control
- Detergent Dispenser
- Hard Food Disposer or Filtration
- Air Dry
- Dry - Heat
- Dry - Max
- Start/Cancel
- Washing Temperature - Sanitize
- Rack Spacer
- 4 Cycles
- Energy Saver
- Quick
- Control Lock
- Rinse Aid Indicator
- CEE Tier 1
- ENERGY STAR Certified
| Product Line | Dishwasher |
| Power Type | Electric 120v |
| Size | 24" |
| Factory | Kinston |
| Color | Stainless Steel |
| Dishwasher | |
| Automatic Temperature Control | Yes |
| Detergent Dispenser | Yes |
| Filter Material | Plastic |
| Filter Trap | Removable |
| Filtered Water | 100 % |
| Hard Food Disposer or Filtration | Yes |
| Motor Speeds | Single-Speed |
| Place Setting Capacity | 14 |
| Rinse Aid Dispenser | Yes |
| Smart Soil Sensor | Yes |
| Lower Spray Arm | Bi-Beam |
| Middle Spray Arm | Bi-Beam |
| Upper Spray Arm | Spray Arm |
| Tub Color | Midnight Ink |
| Tub Design | Tall Tub |
| Tub Material | Plastic |
| Wash Levels | 5 |
| Wash System | Direct Feed |
| Water Pressure | 120 psi |
| Water Usage | 3.2 Gallons |
| Dishwasher Cycles | |
| Energy Saver | Yes |
| Heavy | Yes |
| Normal | Yes |
| Number of Cycles | 4 |
| Quick | Yes |
| Dishwasher Options | |
| Air Dry | Yes |
| Dry - Heat | Yes |
| Dry - Max | Yes |
| Drying System | Static Vent |
| Heated Dry | Yes |
| High Temperature | Yes |
| Start/Cancel | Yes |
| Washing Temperature - High | Yes |
| Washing Temperature - Sanitize | Yes |
| Lower Rack | |
| Maximum Height Clearance | 13" |
| Minimum Height Clearance | 11" |
| Number of Silverware Basket | 1 |
| Number of Silverware Basket Lids | 2 |
| Rack Coating | PVC |
| Rack Type | Standard |
| Upper Rack | |
| Minimum Height Clearance | 8" |
| Rack Coating | PVC |
| Rack Spacer | Yes |
| Rack Type | Standard |
| General Specifications | |
| Sound Level | 54 dBA |
| Annual Energy | 240 kWh |
| Product Weight | 56 lbs |
| Prop 65 Label | Yes |
| Warranty - Labor | 1 Year |
| Warranty - Parts | 1 Year |
| Controls | |
| Control Location | Front |
| Delay Start Hours | 4 Hours |
| Control Lock | Yes |
| Rinse Aid Indicator | Yes |
| Exterior | |
| Door and Handle Design | |
| Door Latch | Pull |
| Door Type | Standard |
| Dimensions and Volume | |
| Minimum Height | 33 1/2" |
| Maximum Height | 35" |
| Width | 24" |
| Depth | 25" |
| Depth With Door Open | 49 1/4" |
| Electrical Specifications | |
| Amps @ 120 Volts | 10 Amps |
| Connected Load @ 120V | 1.2 kW |
| Voltage Rating | 120 V |
| Installation | |
| Connection Location | Right Bottom |
| Number of Leveling Legs | 4 |
| Water Inlet Location | Left Bottom Front |
| Performance Certifications and Approvals | |
| CEE Tier | Tier 1 |
| ENERGY STAR Certified | Yes |
| UL Listed | Yes |
| cUL Listed | Yes |
| Meets ASSE 1006 Requirements | Yes |
| NSF Certified | Yes |
