Ge Appliances UUC148WCDA 208-230V 48,000 Btu Side Discharge Air Conditioner Condensing Unit
Ge Appliances UUC148WCDA 208-230V 48,000 Btu Side Discharge Air Conditioner Condensing Unit
SKU: UUC148WCDA
Compact Size Side-Discharge Configuration Is Perfect For Installation In Limited Space ... Read more...
Colors:
WhiteWhen Will I Get My Order?
x
When Will I Get My Order?
x
Ge Appliances UUC148WCDA 208-230V 48,000 Btu Side Discharge Air Conditioner Condensing Unit
Compact Size Side-Discharge Configuration Is Perfect For Installation In Limited Space Light Weight Easier Contractor Equipment Transportation And Installation Quiet Operation Sound-Dampening Features Produce Operation At Noise Levels As Low As 52Db 24V System Compatible With Many 24Vac Thermostat Ahri Matching Indoor Coil Independent 3Rd Party Coil Match Available See Specification Book For Full Heating, Cooling, And System Details
- Compact Size
- Light Weight
- Quiet Operation
- 24V System
- AHRI Matching Indoor Coil
- See specification book for full heating, cooling, and system details
| CAPACITY | |
| Cooling BTUH (MAX) | 46000 Btu |
| APPEARANCE | |
| Color Appearance | White |
| POWER / RATINGS | |
| Cooling Rated Capacity BTU/Hr | 46,000 |
| Minimum Circuit Amp | 26 |
| WARRANTY | |
| Parts Warranty | 10-Year Limited Parts and Compressor Warranty with Registration Limited 5-Year Parts and Compressor |
| WEIGHTS & DIMENSIONS | |
| Net Weight | 198 lb |
| Suction O.D. Refrigerant Line | 3/4' |
| Liquid O.D. Refrigerant Line | 3/8' |
| Overall Depth | 20.875 in |
| Factory Charge (pounds) | 8.8000001907349 lb |
| Overall Width | 43.375 in |
| Overall Height | 34.25 in |
| Approximate Shipping Weight | 198 lb |
| FEATURES | |
| Style | Side-Discharge |
| Model Type | Indoor |
| Refrigerant Type | R410A |
| Maximum Line Length (Ft/M) | 98/30 |
| Series | Side-Discharge |
| Maximum Height (Ft/m) | 50/15 |
| Temperature Range - Cooling Mode | 50-115 F (10-46 C) |
| SEER | 14 |
| Compressor Type | Scroll |
| Maximum Fuse Size A | 40 |
| EER | 11.7 |
| Fan Speed RPM | 900 |
| Outdoor Noise Level | 60 dBA |
| Outdoor Airflow CFM | 2600 |
| CFM with Rated Coils | 1325 |
| Aspen Model | C(A,C,E)48C34+TDR |
| Product Type | Multi Zone Single Zone |
