Ge Appliances UUC130WCDA 208-230V 30,000 Btu Side Discharge Air Conditioner Condensing Unit
Ge Appliances UUC130WCDA 208-230V 30,000 Btu Side Discharge Air Conditioner Condensing Unit
SKU: UUC130WCDA
Compact Size Side-Discharge Configuration Is Perfect For Installation In Limited Space ... Read more...
Colors:
WhiteWhen Will I Get My Order?
x
When Will I Get My Order?
x
Ge Appliances UUC130WCDA 208-230V 30,000 Btu Side Discharge Air Conditioner Condensing Unit
Compact Size Side-Discharge Configuration Is Perfect For Installation In Limited Space Light Weight Easier Contractor Equipment Transportation And Installation Quiet Operation Sound-Dampening Features Produce Operation At Noise Levels As Low As 52Db 24V System Compatible With Many 24Vac Thermostat Ahri Matching Indoor Coil Independent 3Rd Party Coil Match Available See Specification Book For Full Heating, Cooling, And System Details
- Compact Size
- Light Weight
- Quiet Operation
- 24V System
- AHRI Matching Indoor Coil
- See specification book for full heating, cooling, and system details
| CAPACITY | |
| Cooling BTUH (MAX) | 30000 Btu |
| APPEARANCE | |
| Color Appearance | White |
| POWER / RATINGS | |
| Cooling Rated Capacity BTU/Hr | 30,000 |
| Minimum Circuit Amp | 14 |
| WARRANTY | |
| Parts Warranty | 10-Year Limited Parts and Compressor Warranty with Registration Limited 5-Year Parts and Compressor |
| WEIGHTS & DIMENSIONS | |
| Net Weight | 141.1 lb |
| Suction O.D. Refrigerant Line | 3/4' |
| Liquid O.D. Refrigerant Line | 3/8' |
| Overall Depth | 17.5 in |
| Factory Charge (pounds) | 7.3000001907349 lb |
| Overall Width | 40 in |
| Overall Height | 32 in |
| Approximate Shipping Weight | 187.4 lb |
| FEATURES | |
| Style | Side-Discharge |
| Model Type | Indoor |
| Refrigerant Type | R410A |
| Maximum Line Length (Ft/M) | 82/25 |
| Series | Side-Discharge |
| Maximum Height (Ft/m) | 33/10 |
| Temperature Range - Cooling Mode | 50-115 F (10-46 C) |
| SEER | 14.5 |
| Compressor Type | Rotary |
| Maximum Fuse Size A | 20 |
| EER | 12 |
| Fan Speed RPM | 880 |
| Outdoor Noise Level | 58 dBA |
| Outdoor Airflow CFM | 2324 |
| CFM with Rated Coils | 1050 |
| Aspen Model | C(A,C,E)36B44+TDR |
| Product Type | Multi Zone Single Zone |
